The FOTON 12,000L water sprayer truck is an efficient and versatile vehicle designed for a wide range of water spraying and transportation applications. This high-quality product from CSCTRUCK is built to deliver top-notch performance, reliability, and durability, making it an ideal choice for customers who need a dependable water sprayer truck for their operations.
Chassis:
This water sprayer truck comes with a sturdy FOTON chassis that is designed to withstand heavy loads and tough operating conditions. With a size of 8,415×2,430×2,920mm, it offers ample space and a comfortable ride. It has a GVW/Curb Weight of 18,000kg/6,340kg, a wheelbase of 4,500mm, and front/rear axles of 6.5/11.5T respectively. The vehicle is equipped with 10.00R20 6+1 tires that provide excellent grip and stability on any terrain.
Engine and Transmission:
The truck is powered by a reliable WEICHAI/WP6.240 diesel engine with a horsepower of 240hp/Euro 3. The engine is paired with a FAST/8JS transmission system with 8 forward and 2 reverse gears. The combination of a powerful engine and smooth transmission ensures efficient and smooth operation, making the vehicle an ideal choice for long-distance transportation and spraying tasks.
Cabin:
The FOTON 12,000L water sprayer truck features a spacious and comfortable cabin that is designed to offer the driver and two passengers a comfortable ride. The cabin has a steel construction, single row, and a flat-type design. It is equipped with all the necessary features such as air conditioning, adjustable seats, and a modern dashboard that provides easy access to all the controls.
Body System:
The tanker capacity of the FOTON 12,000L water sprayer truck is 12CBM, with a stainless steel 304 material and a thickness of 6mm. It is built to withstand heavy loads and tough operating conditions, making it an ideal choice for a wide range of applications. The truck is equipped with a self-priming sprinkler pump made of stainless steel that has a flow rate of 60m³/h and a lift height of 90m. It is designed for front flushing, side spraying, and rear sprinkling, and comes with a platform with a water cannon and water gun. The water cannon can be rotated 360 degrees, and the water flow can be adjusted to heavy, medium, light rain, drizzle, and mist.
Other Parts:
The FOTON 12,000L water sprayer truck comes with several other essential parts that include a self-flow valve 1pc, a fire joint 1pc, and water pipes 2pcs. These parts ensure that the vehicle operates at maximum efficiency and provides reliable performance. Overall, the FOTON 12,000L water sprayer truck is a high-quality product that offers excellent value for money and is ideal for a wide range of water spraying and transportation applications.
| Chassis | FOTON |
| Size | 8,415×2,430×2,920mm |
| GVW/Curb Weight | 18,000kg/6,340kg |
| Wheelbase | 4,500mm |
| Front/Rear Axle | 6.5/11.5T |
| Tire | 10.00R20 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | WEICHAI/WP6.240/240hp/Euro 3 |
| Transmission | |
| Make/Model | FAST/8JS |
| Gears | 8F+2R |
| Operation | Manual |
| Cabin | |
| Driving | FOTON AUMARK 4×2 Day Cab, Left-hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Body System | |
| Tanker Capacity | 12CBM |
| Shape | |
| Material | Stainless steel 304 |
| Thickness | Tank Body 6mm |
| Performance | |
| Spraying Width(m) | ≥14m |
| Canon Range(m) | ≥35m |
| Suction Height | >7m |
| Full Tank Suction Time | <15 minutes |
| Equipment | |
|
Sprinkler Pump |
Front flushing, side spraying, rear sprinkling nozzle, and platform with water cannon and water gun.
The water cannon can be rotated 360 degrees. The water flow can be adjusted to heavy, medium, light rain, drizzle, and mist. |
| Type | Stainless steel self-priming sprinkler pump |
| Flow Rate | 60m³/h |
| Lift Height | 90m |
| Self-priming Height | 7m |
| Other Parts | |
| Include | Self-flow valve 1pc; Fire joint 1pc; Water pipe 2pcs |
