specification
|
Sweeping performance |
Sweeping Efficiency |
≥95% |
|
|
Max. Sucking Dust Diameter |
120 mm |
|
|
Sweeping Width |
2.8-3.0 m |
|
|
Max. Sweeping Capacity |
60000 m2/h |
|
|
Extensive Length of disc brush |
≥400 mm |
|
|
driving speed while sweeping |
3-20 km/h |
|
Auxiliary engine |
brand |
JMC |
|
|
Model |
JX |
|
|
Horsepower |
87HP |
|
Water tank |
Water Tank Capacity |
1200lt |
|
|
Water Tank Material |
304 stainless steel |
|
Hopper |
Hopper Capacity |
4.2 m³ |
|
|
Hopper Material |
304 stainless steel |
|
|
Hopper Thickness |
3mm |
|
|
titling angle of the garbage container |
≥46° |
|
|
titling angle of discharge door |
≥85° |
|
Hydraulic |
Mold |
electrical control |
|
|
main components |
Gear pump, hydraulic motor, hydraulic cylinder, and electromagnetic valve |
|
|
pressure |
16 MPa |
|
|
capacity of the hydraulic oil |
60 L |
|
|
Temperature of the oil |
60 ˚C |
|
|
Hydraulic multi-way valve brand |
Taiwan |
|
|
Hydraulic oil tank Cap. |
60lt |
|
Electrical System |
Mold |
DC12 V |
|
|
Voltage |
12 V |
|
|
Battery |
12V |
|
|
Control switches brand |
Schneider |
|
Spraying system |
main components |
Electrical membrane pump, water filter, nozzles |
|
Disc Brushes |
type |
4 disc brushes located, driven by hydraulic motor; front right brush could be controlled separately, it has the function of avoiding and reset |
|
|
diameter of the brush |
≥450 mm |
|
|
sweeping titling angle |
Front：4-6 degree side ：4-7 degree |
|
suction device |
type |
Single Suction Mouth，hydraulic control |
|
Moving pipe |
Pipe length |
4m |
|
|
Pipe diameter |
6” |
|
Middle Brush |
Installed |
1pc |
|
Vacuum |
Capacity |
13.200m3/hr |
|
Water |
Sprinkling pressure |
4bar |
|
|
Nozzle units |
≥12pcs |
