Municipalities shall add this sewer tuck to their fleets as a fast-response, emergency backup vehicle. And big communities could use the combo sewer cleaning truck as a low-cost alternative for regular maintenance and storm water line problems. Contractors and utilities choose it for the lower operating costs and great versatility. When you need a quick response, call us. This powerful enough vehicle will be your best choice for lower transporting costs and greater loading capacity and it’s designed and manufactured to the same exacting standards.
Our Jet-Vac Trucks are Available in:
● 4CBM Vac Jet Combination Truck
● 6CBM Combination Sewer Cleaning Truck
● 8CBM Combined Vacuum Sewer Truck
● 10CBM Combined Sewer Cleaner Truck
● 12CBM Combination Sewer Jetter Truck
● 14CBM Combination Sewer Jetting Truck
● 16CBM Combination Jetting Cleaning Truck
● 18CBM Combo Sewer Jetter Truck
● 20CBM Combo Sewer Cleaning Truck
KEY FEATURES
● Dual Engine
● Tank Capacity 20CBM
● GVW 31000kg
● Vehicle Weight 17000kg
● Tank length 7300mm, diameter 24 00mm
● Overall Size 11990×2500,2550×3980(mm)
● Gravity discharging mode and pressure reverse discharging mode can be selected.
● 10000Liters effective volume of the sewage tank and 6000liters water capacity in a unitized tank.
APPLICATION
● Municipalities
● Big Communities
● Industrial Contractors
● Utilities
● Large Chemical Plant
STANDARD SPECIFICATION
| Chassis Make | Dongfeng KL |
| Wheelbase | 1850+4600+1350 mm |
| Gross Vehicle Weight | 31000kg |
| Transmission | FAST 12 Speed forward 2-speed reverse |
| Chassis Engine | Cummins engine 385, diesel |
| Front Axle | 6.5Ton,6.5Ton |
| Rear Axle | 18Ton double rear driven axles |
| Tires | 12R22.5 13 pcs |
| Function | High-pressure flushing, sewage cleaning |
| Debris Partition | Round type, a material with 6mm steel, 12m3 |
| Water Partition | 8 mm steel, with 3 top manholes, volume 8m3 |
| Water Pump | Standard on Chinese local brand plunger pump |
| Water Loading Valve | Hydrant connect |
| Capacity | 18m3 /hour |
| Max Flow | 270L/Min |
| Max Pressure | 24Mpa |
| Nozzles | 20 pcs |
| Vacuum System | Vacuum suction loading, pressure discharging |
| Vacuum Pump | SK42 Water Circulating Liquid Ring Pump |
| Filtration System | Stainless steel filtration pump and tank |
| Discharge Port | 600 Hydraulic open discharge valves |
| Discharge Port | 150mm Manual open discharge valve |
| Suction Port | 100mm inner suction hose connects |
| Air Release Valve | 100mm for air release |
| Side Platform | Full tank length on both sides of the platform |
| Hose Reel | Super duty removable hose reel with 100m water hose with steel reinforced. |
| Level Indicator | Acrylic sight glass level |
| Suction Hose | 8 m suction hose |
| Read Lids | Hydraulically Open rear door equipped latch 4 pcs |
| Lights | LED lighting system rear with arrow lighting |
| Tank Dumping | Minimum 45°, T lift hydraulic lift |
| Auxiliary Engine | WeiChai 420hp |
| Engine Water Tank | Stainless steel water recycling tank, a water pipe with hand washing tap. |
| Toolbox | 2-floor toolbox with independent space |
| Safety | Automatic Vacuum Breaker overfill protection system |
PICK UP A CHASSIS
We offer oil tank trucks on a variety of chassis including ISUZU, HINO, UD, JAC, SINOTRUK, SHACMAN, BEIBEN, and DONGFENG, available on any commercial chassis.
*Please scroll down to see this Municipal Vacuum Tank Truck chassis inventory, you may optional choose above different brand of chassis for one of your tanks, or need a new tank for one of your truck chassis for mounting this Municipal Vacuum Tank. There is the one you need.
BENEFITS
● Super Tank Capacity for heavy sewage loading and long-distance transportation
● Simple Structure ease of maintenance
● Multifunctional vehicle, Combinate with sewer cleaning, suction, water jetting, water recycling
● Competitive selling price
