Rear Loader Garbage Truck

The rear loader garbage truck is also what we usually call a "rear loader compactor garbage truck", which is mainly relative to the side loader garbage truck. Compactor garbage trucks can self-load, compress, and transfer the barreled domestic garbage in grass-roots communities. The volume is reduced after compression, and the transport efficiency is high. Especially with the gradual deepening of garbage classification, the efficiency of transporting the classified barreled garbage by a compressed garbage truck is greatly increased.

Different regions and different communities have different methods of grassroots collection. Different collection methods mean different charging structures are required for docking. The following will introduce several common styles of the loading mechanism of the rear loader compactor garbage truck filler.

The most common garbage collection at the grassroots level is the 120/240L trash can. The turning mechanism can hang 2-3 120/240L square trash cans at the same time, and dump the garbage at the same time. It is used in conjunction with the pneumatic sealing cover, and the pneumatic cover is sealed after the filling is completed, so as to avoid the waft of garbage and odor during the transfer process. In addition to 120/240L square trash cans, 300/360L round trash cans are still being used in some areas, and 660L square trash cans are being used in some areas. This structure is basically the same as the 120/240L trash can turning mechanism, except that the structure of the 660L square bucket and the 300/360L round iron bucket is equipped with a bucket hook. The above two structures can almost cover most of the common ones on the market. garbage can.

In some areas, in addition to hanging trash cans, garbage from small collection vehicles such as rickshaws and tricycles needs to be connected to the compressed garbage truck for compression and transfer, which requires a small garbage bucket that can be landed. After the small triangular garbage bucket is put down, it is flush with the ground. The garbage from the rickshaw tricycle can be directly dumped into the triangular garbage bucket. After the triangular garbage bucket is turned over, the garbage is poured into the compression box. At the same time, the triangular garbage bucket can be equipped with hooks to fix 120/240L garbage cans, which can meet the collection and transfer needs of hanging buckets and tricycle rickshaws at the same time.

The principle of the big drop bucket is similar to the small triangle bucket above, but the actual structure is different and the cost is slightly higher. The garbage bucket is relatively large, which is suitable for docking and dumping collection of collection vehicles such as forklifts, small dump garbage trucks, sealed garbage trucks, and hanging bucket garbage trucks. The hopper can be folded up to replace the sealing lid of the filler. Beautiful appearance, no drifting and dripping during driving. Generally suitable for medium and large compression garbage trucks.

The swing-arm structure is matched with a swing-arm garbage can. The garbage can is generally made of carbon steel, which has a large volume and is durable. A swing-arm mechanism is used to dump the garbage in the garbage can during the filling period. Because the swing arm type garbage bin is relatively large in volume and heavy in weight, it is necessary to install rear hydraulic outriggers. If necessary, a bucket hanging mechanism can be installed. The structure of the swing arm type is more complicated and the cost is higher. In addition, the garbage bin is not suitable for the current trend of garbage classification. At present, the swing arm type compression garbage truck is gradually declining.

The above introduces several styles of common compactor garbage truck loading structures. There are many types of garbage trucks, different structures, rich brands, and configurations. There are many kinds of loading structures of the rear-loading compression garbage truck alone, and the special-shaped structure can also be customized according to the actual use of the user. Therefore, users who need garbage trucks can communicate with CSCTRUCK Municipal about their actual usage according to their needs, in order to choose the most suitable garbage trucks for them. In order to maximize the efficiency of garbage collection and processing.

Rear Loader Garbage Truck

ProductsENGINE CAB TRUCKGVWGARBAGE CONTAINER CAPACITY
FAW 20CBM Rear Loader Refuse Truck290 hpFAW- J5N 28.290 FL25 Ton
20 CBM
SINOTRUK Rear Loader Container Garbage Truck140 hpSINOTRUK - HOWO10 Ton
8 CBM
SINOTRUK 10CBM Rear Loader Waste Truck160 hpSINOTRUK - HOWO12 Ton
10 CBM
SINOTRUK 20CBM Rear Loader Refuse Truck370 hpSINOTRUK - HOWO25 Ton
20 CBM
DONGFENG 20CBM Rear Loader Trash Truck325 hpDONGFENG - KL25 Ton
20 CBM
ISUZU 20CBM Rear Loader Trash Truck300 hpISUZU - FVZ25 Ton
20 CBM
SHACMAN 20CBM Rear Loader Refuse Truck375 hpSHACMAN - H300025 Ton20 CBM
FOTON 18CBM Rear Loader Trash Truck300 hpFOTON - AUMAN25 Ton18 CBM
DONGFENG 18CBM Rear Loader Trash Truck270 hpDONGFENG - CLASSIC25 Ton18 CBM
ISUZU 12CBM Rear Loader Garbage Truck205 hpISUZU - FTR16 Ton12 CBM
FAW 12CBM Rear Loader Garbage Truck220 hpFAW - J5K16 Ton12 CBM
FOTON 10CBM Rear Loader Garbage Truck136 hpFOTON - AUMARK12 Ton10 CBM
Dongfeng 12CBM Rear Loader Garbage Truck190 hpDONGFENG - KR16 Ton12 CBM
SINOTRUK 12CBM Rear Loader Garbage Truck
266 hpSINOTRUK - HOWO16 Ton12 CBM
DONGFENG 10CBM Rear Loader Waste Truck170 hpDONGFENG - DFAC12 Ton10 CBM
ISUZU 14CBM Rear Loader Refuse Truck240 hpISUZU - FVR18 Ton14 CBM
SHACMAN 12CBM Rear Loader Garbage Truck210 hpSHACMAN - L300015 Ton12 CBM
DONGFENG 14CBM Rear Loader Refuse Truck210 hpDONGFENG - KR16 Ton14 CBM
FAW 18CBM Solid Waste Disposal Truck340 hpFAW25 Ton18 CBM
SHACMAN 14CBM Waste Compactor Truck210 hpSHACMAN - L300018 Ton14 CBM
ISUZU 600P Garbage Compactor Truck96 hpISUZU - 600P7 Ton5 CBM
DFAC Rear Loader Trash Garbage Truck119 hpDONGFENG - DFAC9 Ton6 CBM
DFAC Refuse Compressor Garbage Truck210 hpDONGFENG - DFAC18 Ton12 CBM
HOWO Rear Loader Garbage Truck136 hpSINOTRUK - HOWO10 Ton6 CBM
Garbage Compacter Truck Without Bin Lifting Facility140 hpDONGFENG - DFAC11 Ton8 CBM
ISUZU Rear Loaders Refuse Garbage Truck190 hpISUZU - 700P10 Ton8 CBM
Shacman Rear Loader Trash Garbage Truck345 hpSHACMAN - H300018 Ton15 CBM
FOTON Rear Loader Refuse Garbage Truck141 hpFOTON - AUMARK9 Ton6 CBM
FOTON Big Rear Loader Rubbish Truck141 hpFOTON - AUMARK12 Ton8 CBM
14CBM Waste Truck Garbage Compressor Refuse Truck190 hpDONGFENG - KR18 Ton14 CBM
ISUZU Small Waste Garbage Compactor Truck120 hpISUZU - 600P8 Ton6 CBM
8CBM Back Loader Recycle Garbage Truck205 hpISUZU - FTR16 Ton8 CBM
DONGFENG Rear Loading Trash Truck130 hpDONGFENG - DFAC11 Ton8 CBM
DFAC Rear Loader Compressed Garbage Truck209 hpDONGFENG - KR18 Ton14 CBM
DFAC Garbage Rear Tipper Truck115 hpDONGFENG - DFAC7 Ton6 CBM
HOWO 14CBM Refuse Collection Truck220 hpSINOTRUK - HOWO18 Ton14 CBM
SHACMAN Automated Side Rear Lift Garbage Truck350 hpSHACMAN - L300025 Ton16 CBM
