| Chassis | |
| Size | 18500*2500*3400(mm) |
| GVW/Curb Weight | 16,000/10,200kg |
| Wheelbase | 4200mm |
| Front/Rear Axle | 5.6T/10.4T |
| Tire | 10.00R20, 10+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | CHAOCHAI/CA6DF2D-22/220HP/Euro 2 |
| Transmission | |
| Make/Model | FAW/CA6TB085M |
| Gears | 6+1 Gear Numbers |
| Operation | Manual |
| Cabin | |
| Driving | FAW J5K 4×2 Night Cab, Right Hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Garbage Container | |
| Capacity | 12 CBM |
| Tank Body Material | High Tensile Carbon Steel |
| Thickness | Side 4mm, Bottom 5mm |
| Design | Sealed leakage proof |
| Working Rotation Speed | 1400r/m |
| Compaction Ratio | 1:3- 1:4 |
| Hopper Volume | 0.8CBM |
| Effective volume of bucket | ≥0.8cbm |
| Loading Time | 8~10s |
| Loading Cycle Time | ≤40s |
| Unloading Time | ≤45s |
| Discharge Type | Rear discharging |
| System Pressure | 16MPA |
| Hydraulic System | Branded oil pump, oil cylinder, valve, gauge, oil tank, pipeline |
| Control System | Multi-Control |
FAW 12CBM Rear Loader Garbage Truck
| Make/Model | CSCTRUCK/RL12CA220R2 |
| GVW | 16,000kg, Heavy Duty Vehicle |
| Cab Truck | FAW J5K 4×2 Night Cab |
| Engine | CHAOCHAI/CA6DF2D-22/220HP/Euro 2 |
| Transmission | CA6TB085M/Manual 6+1 Speed |
| Garbage Container Capacity | 12 Cubic Meter |
| Hopper Capacity | 1.5~2 Cubic Meter |
| Certification | ISO9001:2015 |
|---|---|
| Chassis Truck | FAW |
| Color | Customized Color |
| Condition | New |
| Country of Origin | |
| Customized | Yes |
| Delivery Time | 50 Days |
| Drive Mode | 4×2 |
| Emission Standard | Euro II |
| Fuel Type | Diesel |
| Intercom | CIF |
| Main Markets | Africa, Eastern Asia, Mid East, North America, Oceania, South America, Southeast Asia |
| Packaging Details | Waxed |
| R&D Capacity | ODM, OEM, Own Brand(CSCTRUCK) |
| Shipping Vessel | Bulk Shipment, Container Shipment, Flat Rack, FR Container Shipment, RORO Shipment |
| Steering | RHD |
| Terms of Payment | T/T |
| Truck Class | Heavy Duty |
| Warranty Period | 12 Months |
