features
-The unique combination of “sealing” and “draining” technology has solved the sewage leakage problem during collection and transportation when the side rear lift garbage truck is working.
-Advanced hydraulic lifting safety circuit is adopted, to ensure the stability and safety of oil cylinder operation.
-Using two-way compression technology, the compression ratio can reach more than 1:2.5, and the compressed domestic waste can reach more than 600-800Kg/m3.
-One cycle time of the filling operation is less than 25 seconds, and one cycle time of the unloading operation is less than 45 seconds.
-Electric and hydraulic control.
-The key components of the electrical system are imported components, such as PLC, proximity switches, buttons, and hydraulic components, which improve reliability.
specification
| Engine | |
| Make/Model | FAST/10JSD160B |
| Type | Diesel Engine |
| Engine System | 4 Stroke, High-Pressure Common Rail, Inter-cooling Turbo-Charged, 4 Cylinders |
| Output Power@ speed | 350hp |
| Emission standard | Euro 5 |
| Transmission | |
| Gears | 10F+2R |
| Operation | Manual |
| Cabin | |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Body and Compaction System | |
| Capacity | 16CBM |
| Material | Weather-resistant steel, high corrosion resistance |
| Design | Sealed leakage proof |
| Compaction Ratio | 1:2 – 1:3 |
| Containers Lifting Devices | High capacity articulated lifter works in a minimum of two stages by four double effects hydraulic cylinders to ensure the lifting and lowering of containers smoothly.
Lifting weight capacity not less than 800 kg. |
| Control System | Equipped with three sets of automatic, manual control, and wireless remote control modes, it can control the operation of the garbage truck in the driver’s cab, the middle of the garbage, and the rear of the garbage. |
