Summary:
The FAW garbage removal compactor truck is a reliable and efficient solution for waste management. This truck is equipped with a 12 CBM garbage container made of high-tensile carbon steel with a thickness of 4mm on the sides and 5mm on the bottom, which ensures a sealed and leakage-proof design. It also has a hopper volume of 0.8CBM and an effective volume of the bucket greater than 0.8cbm. The compaction ratio ranges from 1:3 to 1:4, making it possible to load a large amount of garbage into the container. With a loading cycle time of less than the 40s, this truck ensures a speedy and efficient garbage collection process.
Features:
The FAW garbage compactor truck is designed for durability and efficiency. It has a size of 8400×2450×3200(mm) and a GVW/Curb Weight of 16,000/9,550kg, making it capable of carrying large amounts of garbage. The truck is equipped with a diesel engine with a make/model of DACHAI/BF6M2012-22/220hp/Euro 3, providing enough power for efficient waste collection. The transmission system has 8F+1R gears and is operated manually. The cabin is made of steel construction, with a single row and a flat design, providing a comfortable driving experience for the driver and two passengers.
The garbage container of this truck has a working rotation speed of 1400r/m, allowing for efficient waste collection. It also has a rear discharging mechanism that can unload garbage in less than 45s. The control system is located in the cab and has rear button control and manual control options, making it easier for the driver to operate the truck. The system pressure ranges from Max.240 bar to a working pressure of 180~200 bar, ensuring safe and reliable operation.
Overall, the FAW garbage removal compactor truck is an ideal municipal truck solution for waste management in urban and suburban areas, providing efficiency, durability, and reliability.
SPECIFICATION
| Chassis | |
| Size | 8400×2450×3200(mm) |
| GVW/Curb Weight | 16,000/9,550kg |
| Wheelbase | 4200mm |
| Front/Rear Axle | 6T/10T |
| Tire | 10.00R20, 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | DACHAI/BF6M2012-22/220hp/Euro 3 |
| Transmission | |
| Gears | 8F+1R |
| Operation | Manual |
| Cabin | |
| Driving | FAW J6P 4X2, Left Hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Garbage Container | |
| Capacity | 12 CBM |
| Tank Body Material | High Tensile Carbon Steel |
| Thickness | Side 4mm, Bottom 5mm |
| Design | Sealed leakage proof |
| Working Rotation Speed | 1400r/m |
| Compaction Ratio | 1:3- 1:4 |
| Hopper Volume | 0.8CBM |
| Effective volume of bucket | ≥0.8cbm |
| Loading Time | 8~10s |
| Loading Cycle Time | ≤40s |
| Unloading Time | ≤45s |
| Discharge Type | Rear discharging |
| System Pressure | Max.240 bar and working pressure 180~200 bar |
| Control System | Front control in the cab, rear button control, and manual control |
