SINOTRUK Rear Loader Container Garbage Truck

Chassis
Size	7350×2250×2750(mm)
GVW/Curb Weight	9,600/5,800kg
Wheelbase	3800mm
Front/Rear Axle	2.4T/7.2T
Tire	7.50R16, 6+1 tires
Engine
Type	Diesel
Make/Model	CHAOCHAI/CY4102BZLQ/140hp/Euro 2
Transmission
Make/Model	WLY/WLY651
Gears	6F+1R
Operation	Manual
Cabin
Driving	SINOTRUK HOWO 4X2 Left Hand Drive
Type	Steel construction, Single Row, Flat
Passenger No.	3
Garbage Container
Capacity	8 CBM
Tank Body Material	High tensile wear-resistant carbon steel
Thickness	Side 4mm, Bottom 5mm
Design	Sealed leakage proof
Working Rotation Speed	1400r/m
Compaction Ratio	1:3- 1:4 (Two-way compression)
Hopper Volume	0.8CBM
Effective volume of bucket	≥0.8cbm
Loading Time	8~10s
Loading Cycle Time	≤40s
Unloading Time	≤45s
Discharge Type	Rear discharging
Hydraulic System Pressure	16MPA
Control System	Front control in the cab, rear button control, and manual control

Certification	ISO9001:2015
Chassis Truck	SINOTRUK
Color	Customized Color
Condition	New
Country of Origin	Made in China
Customized	Yes
Delivery Time	50 Days
Drive Mode	4×2
Emission Standard	Euro II
Fuel Type	Diesel
Intercom	CIF
Main Markets	Africa, Eastern Asia, Mid East, North America, Oceania, South America, Southeast Asia
Packaging Details	Waxed
R&D Capacity	ODM, OEM, Own Brand(CSCTRUCK)
Shipping Vessel	Bulk Shipment, Container Shipment, Flat Rack, FR Container Shipment, RORO Shipment
Steering	LHD
Terms of Payment	T/T
Truck Class	Medium Duty
Warranty Period	12 Months
