DONGFENG 18000 Liter Sanitation Road Water Bowser Truck

BRIEFS:

Introducing the Dongfeng 18000 Liter Sanitation Road Water Bowser Truck, a versatile and robust vehicle designed for water transport and sanitation tasks. This 6×4 water tank truck is engineered to efficiently manage water resources for various applications, including road cleaning and sanitation operations. With its powerful engine and ample tank capacity, it’s a reliable choice for maintaining cleanliness and hygiene on urban streets and highways.

The Dongfeng Sanitation Truck is the ideal solution for municipalities, sanitation departments, and other organizations seeking an efficient and reliable vehicle for water transport and sanitation operations. Its combination of power, versatility, and advanced features makes it a valuable asset for maintaining cleanliness and hygiene in urban areas.

FEATURES:

1. Impressive Dimensions: The Dongfeng 6×4 Water Tank Truck boasts dimensions of 10120/10140 x 2550 x 3190 mm, providing a spacious and functional chassis for water transport.
2. High Payload Capacity: With a total mass of 25000 kg and a rated payload of 13690 kg, this truck is well-equipped to handle substantial water loads while maintaining stability.
3. Robust Construction: Built with a sturdy carbon steel tank material, this bowser truck ensures durability and long-lasting performance, even in challenging environments.
4. Powerful Engine: The D6.7NS6B290 engine, rated at 290 Hp, delivers the necessary power to propel the vehicle and operate the water pump efficiently.
5. Fuel Efficiency: Operating on diesel fuel, this truck offers an optimal balance of power and fuel economy, making it cost-effective and eco-friendly.
6. Advanced Chassis: The 6×4 driving type, 10-speed manual gearbox, and dual-circuit pneumatic brake system provide precise control and safety during operation.
7. Ample Tire Configuration: Equipped with 295/80R22.5 18PR and 11.00R20 18PR tires, including a spare, this truck ensures reliable grip on various road surfaces.
8. Flexible Water Discharge: The front flushing, rear spraying, side spraying, and S-type water spraying anti-aircraft gun offer multiple water discharge options for different applications.
9. Exceptional Reach: The rear platform sprinkler’s anti-aircraft gun has a lifting capacity of 30-35 meters, allowing for efficient water distribution over large areas.
10. Precise Control: The vertical suction head of the sprinkler pump reaches 6 meters, providing precise control over water suction and discharge.
11. Comprehensive Safety: The truck features a parking brake with an energy storage spring air cutoff brake and an auxiliary engine exhaust brake for enhanced safety during operation.
12. Optional Spray Range: With an optional 30-120 meter spray range, this truck can adapt to a wide range of sanitation and water distribution tasks.





SPECIFICATIONS:

Name	DONGFENG 18000 Liter Sanitation Road Water Bowser Truck
Dimensions (LxWxH)	10120/10140 x 2550 x 3190 mm
Total Mass	25000 kg
Rated Payload	13690 kg
Curb Weight	11180 kg
Passengers	3
Approach/Departure Angle	20/10

Chassis Parameters:

Model	DFH1250D4
Driving Type	6×4 left/right hand drive
Wheelbase	4350+1350 mm
Gearbox	10-speed forward and 2 reverse, manual
Tire	295/80R22.5 18PR, 11.00R20 18PR
Number of Tires	10 + 1 (spare tire)
Front/Rear Suspension	1860/1860 mm
Brake System	Service brake: dual-circuit pneumatic brake<br>Parking brake: energy storage spring air cutoff brake<br>Auxiliary brake: engine exhaust brake

Engine Parameters:

Manufacturer/Model	D6.7NS6B290
Rated Power	290 Hp
Fuel Type	Diesel oil
Displacement/Capacity	6700 ml
Emission Standard	Euro 3

Equipment Parameters:

Tank Capacity	18.5 m3
Tanker Material	Carbon steel
Front Flushing Water Spraying Width	15-20 m
Rear Platform Sprinkler Anti-aircraft Gun Lift	30-35 m
Vertical Suction Head of Sprinkler Pump	6 m
Standard Configuration	Front flushing, rear spraying, side spraying, S-type water spraying anti-aircraft gun, fire interface
Optional	30-120 m spray
