specification

Model	CSC5020TSLE
Overall Dimension	4100×1500×1900 mm
Chassis Engine	JL466Q4
Chassis Model/ Make	SC1022DB4N/ Chang-an
Chassis Engine Power	39 kW @ 5300RPM
Cabin	A/C
Max Sweeping Width	2100 mm
Max. Sweeping Capacity	42000 m²/h
Sweeping Speed	3 ～ 10 km/h
Dust Suppression Speed	10 ～ 20 km/h
Sweeping Productivity	≥ 92%
Max Debris Sucted in	60 mm
Oil Consumption @ Working	≤4.0 L/h
Oil Consumption @ Driving	7.7 L/100km
Stainless Steel Hooper Volume	1600 L
Plastic Water Tank Volume	370 L
Hooper Dump Angle	0≥50
Gradeability	0.3
Min Turning Radius	11 m
Brake Distance	≤10 m Full loaded @ speed 30km/h
Max. Driving Speed	98 km/h
Max Loading Capacity	1810 kg
