● Sludge Tank 6,000 Liters, Water Tank 4000 Liters
● Round Shaped, Rear Lids Openable
● Optional Pumping System
● Dongfeng Truck Chassis
● 50m Rear Hose Reel
● Multiple Discharge Ports
STANDARD SPECIFICATION
| Truck Chassis Make | Dongfeng Dollicar |
| Wheelbase | 3800 mm |
| Chassis Engine Make | ChaoYang Diesel Engine |
| Engine Model | CY4102-E3C |
| Engine Horse Power | 88 (kW) 120hp |
| Emission Standard | Euro 3 |
| Fuel Type | Diesel |
| Combination Dimension | 7040×21800×2610 mm |
| GVW | 9000kg |
| Water Tank Volume | 3000Liters |
| Water Pump (Standard) | TONGJIE™ Plunger Pump |
| Flow Capacity | 210 L/min |
| Max. Pressure | 20 Mpa |
| Water Pump (Optional) | Italy HPP/ PRATISSOLI Plunger Pump |
| Vacuum Pump | WEILONG™ PTO Driven Vacuum Pump |
| Vacuum Pump (Optional) | Italy JUROP, MORO |
| Air Flow | 15000 L/min (900m3/hour) |
| Vacuum | 90% |
| Sludge Tank Volume | 3000Liters |
| Suction Depth | >8m |
| Tipping Tank | 45º |
| Vacuum Pressure | >0.8 bar |
| Suction Time | <5 min |
| Discharge Time | <5 min |
| Water High-Pressure Hose | 60m ×22mm diameter |
| Suction Hose | 10m×125mm diameter |
| Flushing Nozzle | Multiple Choice |
