STANDARD FEATURES
● Volume 4000 liters, Sludge Tank 2000 lt, Fresh Water Tank 2000 lt.
● Level Indicator.
● Tank Interior with a epoxy and polyurethane painting.
● Inside Tanker with baffles avoid of splash over and swinging of water.
● Suction hose set and special containers for all suction hoses.
● Manually controlled Sludge suction, 4″ and 5″ suction valves with a quick coupling.
● Manually controlled Sludge discharge, gate type, 6″ discharge valve with a quick coupling.
● Hatch of water tank be sealed from spillover of water and include an air breather;
● Fresh water inlet by a diameter of DN80 camlock coupling manually operated valves for opening and closing.
● Manhole Located on the fresh water compartment with a dia. of 500mm. Lockable cover.
● SK-6 Vacuum Pump (Water Circulating). Pressure 160Bar. Located under the vacuum tank.
● Top of tank with stainless steel floating ball – shut off system.
● Pressure relief system providing the secure working conditions.
● Italy HPP Water pump, High pressure water plunger pump.130L/min.
● Control System fixed on the backside of the tank and remote control for boom system.
● Control panel is made of stainless steel materials and contains the below sub units
● Hose reels are placed on the right lower corner of the tank and can be operated manually.
● Small high-pressure hose reel design (m) 60.
● Bursting Pressure: More than 160 bar.
● Hose reel on rear of the tank. Manually. Equipped with a water cleaning gun.
● Rear door hydraulic opening/ closing/ locking/ unlocking.
● Hose trays: 1 unit with 8-meter cable for the suction boom system.
● Access ladder: 200 kg lifting capacity.
● Warning lamp: 1 unit fixed at the rear of the tank , 1 unit with 6 meter extension cable.
● Mud guard: Polyethylene, made for the rear wheels of the truck.
● Suction hoses: Total of 16 meters, high endurance suction hoses with the following configuration.
● Dia. of 4″, 4-meter suction hose, with quick couplings at the ends (4 units).
● Water filling hose: 2 units, 10-meter length.
● Other accessories: Toolbox, firefighting set, jack, air hose with pressure meter.
CHASSIS RECOMMENDATION
| Gross Vehicle Weight | 7500kg |
| Wheelbase | 3308mm |
| Front Axle | 1800kg |
| Rear Axle | 3500kg |
| Clear C.A. / C.B. | 3960mm C.A. |
| After Frame from Center of Rear Axle | 1852mm |
