HOWO 12000 Liter Sludge Sewer Suction Vacuum Truck

Brief:

The HOWO 12000 Liter Sludge Sewer Suction Vacuum Truck is a powerful and efficient solution for sewage and sludge removal. Built on a robust chassis, this vacuum truck offers exceptional performance and reliability. With a spacious cabin for a crew of three, it ensures a comfortable working environment. Equipped with a high-capacity tank and a powerful vacuum pump, it can handle a wide range of suction tasks. The truck’s advanced features, including optional accessories, make it a versatile choice for various applications.

This sewer suction vacuum truck is a versatile and efficient solution for waste management, designed to meet the demands of various industries and applications. With its powerful performance, ease of operation, and a range of accessories, it ensures reliable and effective waste removal.

Features:

1. Dimensions: Compact and maneuverable with dimensions of 7500 x 2470 x 3050 mm, allowing access to tight spaces.
2. Total Mass: Heavy-duty design with a total mass of 29,800 Kg for stable and efficient operations.
3. Payload Capacity: Rated for a payload of 16,000 Kg, ensuring ample capacity for waste collection.
4. Kerb Weight: Balanced kerb weight of 13,800 Kg for optimal performance.
5. Passenger Capacity: Accommodates a crew of three, ensuring a productive and comfortable working environment.
6. Approach/Departure Angle: Impressive approach and departure angles of 33/22 for tackling various terrains.
7. Chassis: Built on a reliable ZZ1607 chassis with a 4X2 configuration, suitable for both left and right-hand drive.
8. Wheelbase: A wheelbase of 4600 mm provides stability and control.
9. Transmission: Features a nine-speed forward and one reverse manual gearbox for versatile control.
10. Tyres: Equipped with 10.00-20 tires, including one spare, for excellent traction.
11. Suspension: Front/rear suspension of 1250/2300 mm ensures a smooth ride.
12. Engine: Powered by a Sinotruck/WD615.87 engine with 290hp, Euro 2 emission standard, and 9,726 ml displacement for robust performance.
13. Cylinder Configuration: A straight 6-cylinder in-line engine with intercooling for efficient power.
14. Maximum Torque: Generates a maximum torque of 1500 N.m for enhanced suction capability.
15. Vacuum Pump: Boasts a vacuum pump with variable speed (800r/m-1400r/m) for efficient suction.
16. Suction Lift: Provides a suction lift of over 6 meters for versatile applications.
17. Vacuum Strength: Achieves a vacuum of more than 500 mmHg for effective waste removal.
18. Rotation Direction: Clockwise rotation for optimal suction performance.
19. Quick Suction: Rapid full suction capability in less than 5 minutes, maximizing productivity.
20. Common Accessories: Includes essential components such as a vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, and optional accessories like a sprinkler and alarm for full suction.



SPECIFICATIONS:

Name	HOWO 12000 Liter Sludge Sewer Suction Vacuum Truck
Dimension (LxWxH)	7500 x 2470 x 3050 mm
Total Mass	29,800 Kg
Rated Payload	16,000 Kg
Kerb Weight	13,800 Kg
Passenger	3
Approach/Departure Angle	33/22

Parameters of the Chassis:

Model	ZZ1607
Driving Type	4X2 (left/right-hand drive)
Wheelbase	4600 mm
Gearbox	Nine-speed forward and one reverse, manual
Front/Rear Track	1900/1800 mm
Tyre	10.00-20
Number of Tyre	6 + 1 (spare tyre)
Front/Rear Suspension	1250/2300 mm
Leaf Spring Number	8/11 + 8

Parameters of the Engine:

Manufacturer/Model	Sinotruck/WD615.87
Rated Power	290hp
Fuel Type	Diesel oil
Displacement/Capacity	9,726 ml
Emission Standard	Euro 2, Euro 3, Euro 4, Euro 5
Cylinder	Straight/6/intercooling
Max. Torque	1500 N.m
Velocity	2200 rpm

Parameters of the Equipment:

Tank Capacity	12m³
Vacuum Pump Rotation Speed	800r/m-1400r/m
Max. Suction Lift	>6m
Vacuum	>500 mmHg
Rotation Direction	Clockwise
Time for Full Suction	<5min
Common Accessories	Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, sprinkler (optional), alarm for full suction (optional).
