Brief:
The ISUZU 25 CBM Stainless Steel Water Sprinkler Tanker Truck, manufactured by CSCTRUCK, is a versatile and robust vehicle designed for water transport and sprinkling applications. With a spacious cab, powerful engine options, and a large 25,000-liter tank capacity, it’s well-equipped to handle various water-related tasks efficiently and effectively.
The water sprinkler tanker truck is a reliable and versatile solution for a wide range of water-related tasks, providing powerful engine options, a spacious cab, and a large tank capacity. Its durability, efficiency, and user-friendly features make it a valuable asset for various industries and applications.
Features:
- General:
- Vehicle Brand: The CSCTRUCK-manufactured ISUZU 25 CBM Stainless Steel Water Sprinkler Tanker Truck is a robust and versatile vehicle designed for various water transport and sprinkling applications.
- Chassis Brand: The truck features a high-quality ISUZU chassis known for its reliability and durability.
- Overall Dimension: With dimensions measuring 1180 x 2500 x 3100 mm, it strikes a balance between maneuverability and carrying capacity.
- GVW / Kerb Weight: The truck has a Gross Vehicle Weight (GVW) of 31,000 kg and a Kerb Weight of 12,000 kg, ensuring a substantial payload capacity.
- Cab:
- Cab Capacity: The spacious and ergonomic cab can comfortably accommodate up to three persons, including the driver.
- Air Conditioner: Equipped with a heating/cooling air conditioner, the cab ensures a comfortable working environment for the crew.
- Engine:
- Fuel Type: Powered by a reliable diesel engine, which is known for its efficiency and fuel economy.
- Engine Brand Options:
- ISUZU 6UZ1-TCG50 (380 HP / 279 KW): This engine variant provides a robust power output of 380 HP (279 KW), making it suitable for demanding tasks.
- ISUZU 6WG1-TCG51 (460 HP / 338 KW): The higher-powered option delivers 460 HP (338 KW), offering enhanced performance capabilities.
- ISUZU 6WG1-TCG62 (520 HP / 382 KW): For maximum power and performance, the 520 HP (382 KW) engine variant ensures excellent acceleration and towing capacity.
- Displacement: With a displacement of 9839 ml, the engine provides ample torque and power.
- Emission Standard: Complies with Euro 5-6 emissions standards, ensuring reduced environmental impact.
- Chassis:
- Drive Type: Featuring an 8X4 configuration with left-hand drive, the chassis offers exceptional maneuverability and control.
- Transmission: Equipped with a FAST 12-speed transmission featuring 2 reverse gears for smooth and efficient operation.
- Wheelbase/No. of Axle: The 1850+4575+1370 mm wheelbase and 4 axles contribute to stability and load-bearing capacity.
- Tire Specification: Fitted with durable 315/80R22.5 tires for optimal traction and performance.
- Tire Number: The truck comes with 12 tires and an additional spare tire, ensuring uninterrupted operation.
- Max Speed: Capable of reaching speeds of up to 95 km/h, making it suitable for various road conditions.
- Paint: The metallic paint finish not only enhances aesthetics but also provides protection against corrosion.
- Superstructure:
- Tank Capacity: Boasting a substantial 25,000-liter tank capacity, this truck is ideal for large-scale water transport and sprinkling tasks.
- Tank Shape: The elliptical tank design optimizes space and distribution efficiency.
- Material: Constructed with robust 4mm carbon steel material, ensuring durability and resistance to wear and tear.
- Body Material: Made from weather-resistant steel, the body can withstand harsh environmental conditions.
- Water Pump: The truck is equipped with a reliable Chinese-brand water pump, ensuring efficient water transfer.
- Loading Type: Featuring self-loading capabilities, the truck can efficiently fill its tank from various water sources.
- Front Spray Bar: A front spray bar enhances water distribution, particularly in road maintenance and dust suppression applications.
- Rear Spray Bar: The inclusion of a rear spray bar ensures comprehensive coverage when dispensing water.
- Water Canon: The powerful 28-meter water cannon offers precision and reach for firefighting or large-area watering tasks.
- Fire Coupling: A standard fire coupling adds an extra layer of safety and versatility.
- Control: Manual control is provided, with an optional air-operated control system for user preference.
- Control Panel: The control panel can be configured in English or your preferred language for ease of operation.
- Optional Features: The truck can be customized with optional equipment such as a backup alarm, a camera system, and language preferences.
- Accessories: It comes equipped with all standard accessories, including warning lights, a music alarm, a basic tool kit, and an English manual.
SPECIFICATIONS:
| General | |
|---|---|
| Vehicle Brand | CSCTRUCK |
| Chassis Brand | ISUZU |
| Overall Dimension | 1180 x 2500 x 3100 mm |
| GVW / Kerb Weight | 31,000 kg / 12,000 kg |
| Cab | |
|---|---|
| Cab Capacity | 3 persons allowed |
| Air Conditioner | Heating/cooling air conditioner |
| Engine | |
|---|---|
| Fuel Type | Diesel |
| Engine Brand | – ISUZU 6UZ1-TCG50 |
| – ISUZU 6WG1-TCG51 | |
| – ISUZU 6WG1-TCG62 | |
| Power | – 380 HP (279 KW) |
| – 460 HP (338 KW) | |
| – 520 HP (382 KW) | |
| Displacement | 9839 ml |
| Emission Standard | Euro 5-6 |
| Chassis | |
|---|---|
| Drive Type | 8X4 (left-hand drive) |
| Transmission | FAST 12-speed levers with 2 reverse |
| Wheelbase/No. of Axle | 1850+4575+1370 mm / 4 |
| Tire Specification | 315/80R22.5 |
| Tire Number | 12 tires and 1 spare tire |
| Max Speed | 95 km/h |
| Paint | Metallic paint |
| Superstructure | |
|---|---|
| Tank Capacity | 25,000 Liters |
| Tank Shape | Ellipse |
| Material | Carbon steel, 4mm |
| Body Material | Weather-resisting steel |
| Water Pump | China famous brand |
| Loading Type | Self-loading |
| Front Spray Bar | YES |
| Rear Spray Bar | YES |
| Water Canon | 28 meters |
| Fire Coupling | Standard |
| Control | Manual (Optional air-operated) |
| Control Panel | English or Your Language |
| Optional | – A backup alarm can be equipped. |
| – Camera can be equipped. | |
| – Operation language can be English or | |
| Appointed language. | |
| – All standard accessories: Warning lights, | |
| music alarm, basic tool kit, English manual. |
