features
-The sweeper has the function of avoidance protection and reset function when encountering obstacles. It retracts after encountering obstacles and resets after crossing obstacles.
-It adopts a full-floating nozzle that can automatically level with the road surface, which has good cleaning effect and long service life.
-The imported hydraulic valve group can ensure the stability and smoothness of the hydraulic action of the whole vehicle.
-The eversion-type vacuuming tube made of imported raw materials can effectively prevent the vacuuming tube from being scratched, freeze-cracked, and increase its service life.
-The high-performance engineering plastic spacer is used in the sweeping arm, which has good wear resistance, and is free of grease and maintenance, saving manpower and material resources.
-Front flushing, rear spraying, spraying, self-cleaning reel, operation monitoring system, auxiliary suction pipe device, snow shovel, etc.are optional.
specification
| nitation Unit | Sweeping Swath | 2.8-3m |
| Working Speed | 3-25 Km/h | |
| Sweeping Capacity | 60000 m2/h | |
| Suction Debris 2 g/cm3 | <100mm | |
| Hopper Tilt Angle | ≥50° | |
| Tanker Capacity | 5 m3 | |
| Hopper Capacity | 4 m3 | |
| Water Tanker Capacity | 1 m3 | |
| Fuel Consumption | Driving | ≤12 L/100km |
| Working Speed | 2.6 L/1000m @ 8km/H | |
| Ancillary Engine | Model | JX493ZG |
| Type | Four stroke water cooing, direct injection diesel engine | |
| Power | 57Kw | |
| Max output speed | 2400RPM | |
| Fuel | 0# light diesel same with chassis truck engine | |
| Make | ISUZU | |
| Air Blower | Type | High pressure, centrifugal, sweeping truck specific used blower |
| Working Speed | 2600～2900r/min | |
| Driving Mode | Drive by ancillary engine, automatic clutch, V belt powered | |
| Hydraulic System | Type | Open type, hydraulic control |
| Main Components | Gear pump, Gerotor motors, Hydraulic cylinders, solenoid valves, IC, manual pump etc. | |
| Oil Pressure Relief | 14MPa | |
| Hydraulic oil level | In 1/2～2/3 position | |
| Hydraulic oil | Working temperature @-30℃～5℃, hydraulic oil is L-HV32 Working temperature @5℃～25℃, hydraulic oil is L-HM46 Working temperature @25℃～40℃, hydraulic oil is L-HM68 |
|
| Oil Tank Capacity | 60L | |
| Hydraulic Pump | Type | Gear pump |
| Displacement | 10 ml/r | |
| Pressure | 14 MPa | |
| Max speed | 3000 RPM | |
| Hydraulic Motor | Type | Gerotor motors |
| Displacement | 160 ml/r | |
| Pressure | 14 Mpa | |
| Max speed | 385 r/min | |
| Washing system | Main component | Electric water pump, water filter, nozzle, water tanker etc. |
| Electric System | Composed | Working with chassis electric system , and Ancillary Engine electric system power supplied with two modules of battery |
| Voltage | 12V | |
| Battery Request | 12-80A.h | |
| Sweeping System | Type | Four disc typed brooms equipped between front and rear axle , symmetric in right and left side of the truck drive by gerotor motors. |
| Broom Size | Φ800mm | |
| Broom Speed | High speed: 110 r/min Medium; 80 r/min low: 60 r/min | |
| Broom Tilt Angle | Front tilt 4°～6° right and left tilt 2°～4° 6°～10° | |
| Suction Nozzle | Type | U shaped servo Suction nozzle |
| Suction Hose Size | Φ190mm | |
| Nozzle Clearance | 5～10mm |
