specification
| Vehicle Model | AUMARK-C38 | |
| Cabin | Single row/W1995/right rudder | |
| Whole vehicle’s main dimensions | Overall dimensions (LxWxH)mm | 6725×2100×2280 |
| Wheelbase(mm) | 3800 | |
| Weight data | Curb weight(kg) | 3305 |
| Gross vehicle weight（kg） | 6500 | |
| Persons in cab | 3 | |
| Whole vehicle’s main performance | Max. speed（km/h） | 95 |
| ENGINE | Model | F3.8s3141 |
| Emissions standards | EuroⅢ | |
| Displacement（L） | 3.76 | |
| Rated Power（kW/rpm） | 105 | |
| Max torque （N.m/rpm） | 450 | |
| Gearbox | Model | 6TS55 |
| Front axle | Type/Mainreducetion ratio | 2.5T |
| Rear axle | Type/Mainreducetion ratio | 6.0T/4.875 |
| Suspension | Front suspension/Leaf spring number | 9 |
| Rear suspension/Leaf spring number | 11+7 | |
| Brake system | Service brake | Drum pneumatic braking |
| Parking brake | Brake gas brake | |
| Auxiliary brake | Engine exhaust brake | |
| Wheels and tyre size | 6+1(8.25R16) | |
| Tanks | volume | Water tank volume: 1.5 square dustbin volume: 4 square |
| Box body material | Material of tank: stainless steel
Dash material: stainless steel |
|
| Sub-engine brand and power | Isuzu Engine Co. Ltd | |
| Cleaning the width | 2.8-3.0m | |
| Operation Ability | 38000(m2/h) | |
| Cleaning speed (km/h) | 15-20 | |
| Cleaning speed (km/h) | 3-15 | |
| Suction capacity | Density (g/cm3) : 2.0 mass (kg) : 1.5 suction particle size (mm) : ≥100 | |
| Garbage box tipping Angle | ≥45° | |
| Cleaning efficiency | ≥96% | |
| The fan system | Special high-pressure centrifugal fan, desktop fan (maintenance free) rated working speed 2700r/min | |
| Suction nozzle device | The suction nozzle is suspended between the rear wheels of the chassis car, which is composed of a suction nozzle, a roller, and a straw. The suction nozzle body can be moved along with the suction nozzle, and the suction nozzle lifting oil cylinder is controlled. | |
| Scanning plate Angle adjustment | Forward scanning plate: forward 5°~15° outward 5°~10° rear scanning plate: forward 5°~10° inward 5°~10 | |
| Single sweep plate with the number of brushes | 22 | |
| Vice frame | Vice beam at the tank bottom | Q345 carbon steel plate |
