features

-The brush drive motor adopts high-quality cycloid hydraulic motor, high working efficiency and long service life.

-A large-area filter screen is set on the top of the container to reduce blockage and ensure smooth suction flow. A diversion groove is set on the top of the box to improve the dust suppression effect, make the garbage accumulation evenly, and increase the effective capacity.

-Both the derbis hopper and the water tank are made of super thick stainless steel plate: In order to prevent the early damage of the water tank and the derbis hopper due to corrosion, which greatly prolongs the service life of the whole vehicle.

-Sweeping device, with automatic obstacle avoidance protection function or automatic reset function. The sweeping broom adopts a spring suspension obstacle avoidance structure to prevent the sweeping brush from being hit by obstacles.

specification

Truck mode		CSC5071TSL6
Sweeping performance	Sweeping Efficiency	≥95%
	Max. Sucking Dust Diameter	120 mm
	Sucking Width	2.8-3.0 m
	Max. Sweeping Capacity	60000 m2/h
	Extensive Length of disc brush	≥400 mm
	driving speed while sweeping	3-20 km/h
Water tank	Water Tank Capacity	1.2 m³
garbage container	Garbage Container Capacity	4.2 m³
	titling angle of the garbage container	≥46°
	titling angle of discharge door	≥85°
hydraulic system	Mold	electrical control
	main components	Gear pump, hydraulic motor, hydraulic cylinder, and electromagnetic valve
	pressure	16 MPa
	capacity of the hydraulic oil	60 L
	Temperature of the oil	60 ˚C
Electrical System	Mold	DC12 V
	Voltage	12 V
	Battery	12V
Spraying system	main components	Electrical pump, water filter, nozzles
Disc Brushes	type	4 disc brushes, driven by hydraulic motor，front right brush could be controlled separately, it has the function of avoiding and reset
	diameter of the brush	850 mm
	sweeping titling angle	Front：4-6 degree     side ：4-7 degree
suction device	type	Single Suction Mouth，hydraulic control
	diameter	200 mm

Spare parts

Ref.	Part name	Quantity
1	Bristles	88
2	seal strip for fan	1
3	seal strip for back door	1
