specification

ISUZU 700P 190HP 4×2 Left Hand Drive

4,475 mm Wheelbase

4HK1-TC51 Engine, 190hp Euro V

700P Day Cab with AC

MLD-6Q Transmission, Manual

Steel leaf spring Suspension

Drum Brake front and rear axle

235/75R17.5Tire with Spare Tire

– Debris Hopper

Capacity: 10m³ stainless steel

Water Tank: 2,500L, Garbage Tank:7.5m³

Self-cleaning device

Hydraulic dumping in-cab control

Overload warning system

– Sweeping Equipment

Four no.side disc typed brooms, hydraulic motor drive

Hydraulic cylinder direction change

Sweeping Width: 3.2m

– Suction Equipment

Centrifugal fan type

Large width suction nozzle, independent

Forward operation, hydraulic raise & lower

200mm diameter suction port

–       Auxiliary Engine

Cummins 140hp

Safety shutdown

Working lights to each side rear and aux engine bay

–       Hydraulic System

Italy BREVINI hydraulic motor

ISAIAM air cylinder
