features

-It integrates road sweeping and high-pressure cleaning, and adopts the method of “two vertical brushes in the middle + ultra-wide suction nozzle in the middle + side spray bar in the middle”, which has high work efficiency, good maneuverability, multi-purpose machine, and high vehicle utilization rate. .

-Centralized operation control in the cab, easy to operate; a manual pump and a spare operation control box are installed outside the cab, which is convenient for emergency use during maintenance.

-A separate auxiliary engine is used to drive the fan and high-pressure water pump and other working devices to ensure that the power can meet the work needs under various driving conditions.

-Scanning disk has automatic avoidance protection function and automatic reset function when encountering obstacles.

-The rotating speed of the sweeping disc can be adjusted to select three gears of high, medium and low according to various cleaning conditions, which can ensure a good cleaning effect under various pollution conditions.

-Adopt advanced and high-efficiency special fan, with excellent anti-seismic and anti-corrosion performance.

-The front and rear clean water tanks are made of high-quality stainless steel. The water tank has a large volume and a long working time.

-The use of self-made wear-resistant brushes greatly reduces the cost of use.

specification

Truck mode	CSC5071TSL6	Remark
Sweeping performance	Sweeping Efficiency	≥95%
Max. Sucking Dust Diameter	120 mm
Sucking Width	2.8-3.0 m
Max. Sweeping Capacity	60000 m²/h
Extensive Length of disc brush	≥400 mm
	driving speed while sweeping	3-20 km/h
Water tank	Water Tank Capacity	1.2 m³
garbage container	Garbage Container Capacity	4.2 m³
titling angle of the garbage container	≥46°
titling angle of discharge door	≥85°
hydraulic system	Mold	electrical control
main components	Gear pump, hydraulic motor, hydraulic cylinder, and electromagnetic valve
pressure	16 MPa
capacity of the hydraulic oil	60 L
Temperature of the oil	60 ˚C
Electrical System	Mold	DC12 V
Voltage	12 V
Battery	12V
Spraying system	main components	Electrical pump, water filter, nozzles
Disc Brushes	type	4 disc brushes, driven by hydraulic motor，front right brush could be controlled separately, it has the function of avoiding and reset
diameter of the brush	850 mm
sweeping titling angle	Front：4-6 degree side ：4-7 degree
suction device	type	Single Suction Mouth，hydraulic control
diameter	200 mm
