HOWO 5000 Liter Vacuum Cleaner Truck Back

HOWO 5000 Liter Vacuum Cleaner Truck

5,000Liters Water Tank
Italy High Pressure Jetting Pump
60-120meters Jetting Hoses
Various Types of Jetting Nozzles
The hose Reel was Rotated and speed-adjusted
HOWO Chassis Truck Adopted

Municipal Truck Inquiry

Categories: Sewer Cleaner Truck, Sewer Truck

BRIEFS

The HOWO 5000 liter vacuum cleaner truck features a comprehensive composition comprising a chassis, transmission assembly, tank assembly, water system, hydraulic system, hose reel, and wash-down system, among other elements. This sewer cleaner truck operational mechanism involves pumping water from the tank using a water pump, pressurizing it through a jetting hose, and directing it through the nozzle. The forceful spray of water from the nozzle propels the jetting hose into the depths of the sewer. Simultaneously, the water’s backward reaction effectively dislodges sludge within the sewer, allowing it to flow downstream with the water, effectively achieving the cleaning and dredging objectives.

FEATURES

Versatile for various sewer cleaning tasks.
Equipped with an enclosed compartment housing the jetting pump with roll-up doors for easy access.
Rotatable wash-down system for enhanced flexibility during operation.
The water tank can be filled either by hydrant or gravity, offering dual filling options.
Constructed from durable carbon steel; optional stainless steel is available. Features a glass-cup type level indicator for convenient monitoring of water levels.

SPECIFICATIONS:

Chassis
Size	6,8302,2002,560 (mm)
GVW/Curb Weight	11,995/6,080kg
Wheelbase	3800mm
Front/Rear Axle	2.7T/7.2T
Tire	8.25R16, 6+1 tires
Engine
Type	Diesel
Make/Model	CUMMINS /ISD3.8S154/ 154HP/ Euro 3
Transmission
Model	WLY/WLY6TS55
Gears	6F+1R
Operation	Manual
Cabin
Driving	HOWO 4×2, Left/Right Hand Drive
Type	Steel construction, Single Row, Flat
Passenger No.	3
Upper Body
Water Tank	5,000Lt, mild steel, manhole on top of water tank
Tank-Chassis Mounting	The water tank mounted on the auxiliary frame to connect with the chassis’ frame
Level Gauge	Liquid level gauge installed on water tank
Water Tank Filling	Can be filled by gravity or hydrant
Water Pump	High-pressure jetting pump, Pratissoli KS40, 140bar
Canal Hose	60-120meters optional
Rear Hose Reel	Rotated and winding & rewinding by hydraulic
Jetting Nozzles	3-4pcs various jetting nozzles
