BRIEF
FEATURES
- Compatible with international DIN standard garbage bins.
- Structured assembly includes arm components, arm cylinders, lifting chains, stabilizers, stabilizer cylinders, multi-valves, etc.
- The operational system comprises PTO, hydraulic pump, multi valves, hydraulic lock, balance valve, hydraulic pipes, and hydraulic oil tank.
- Equipped with a balance valve to synchronize lifting arms and prevent gravitational arm descent.
- Features a hydraulic oil tank filter to maintain the cleanliness of the entire hydraulic system.
- Utilizes high-quality paint for enhanced appearance and corrosion resistance in the upper structure.
SPECIFICATIONS:
| Chassis | |
| Size | 6,000*2,100*2,900mm |
| GVW/Curb Weight | 6,600/3,600kg |
| Wheelbase | 3,360mm |
| Front/Rear Axle | 2T/4.8T |
| Tire | 7.00R16, 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | ISUZU / 4KH1CN5LS/ 98hp/ Euro 5 |
| Transmission | |
| Model | ISUZU/MSB5 |
| Gears | 5F+1R |
| Operation | Manual |
| Cabin | |
| Driving | 4×2 |
| Type | ISUZU |
| Passenger No. | 3 |
| Skip Loader | |
| Skip Bin Cubage (CBM) / Capacity (Tons) | 4/3 |
| Skip Bin Shape | Square, boat or other types on requirement |
| Skip Loader Material | Mild steel |
| Control System | Manual hydraulic control & remote control |
| Lifting Arm | 2pcs, strong alloy steel material |
| Chain | Rings of thickened chains, with large and small holes, not easy to fall off and deform |
| Stabilizers | 2pcs, hydraulic type, stable & high-strengthen |
| Painting | Anti-corrosion treatment for all structural parts
Steel components are sprayed with high quality paint |
