Tipping Tank:
- Sludge Tank (Thickness 5mm steel) Volume: 1000 lt. Water Tanker(Thickness 5mm steel ) 2000L
- Combination wash /Hydro Vac system
- WEILONG Vacuum pump, TONGJIE Plunger Pump (16Mpa, 160L/min)
- 60M pressure hose, 19mm diameter, Reel speed at 0-25m/min
- Water flushing width 2.5m-3.5m, pressure 9Mpa, 160L/min, Cleaning width > 16m, Water Gun Range >38m.
- Sludge Tanker rear tipping
- High-capacity cyclone with full opening lid.
- 2” quick-acting brass drain valve (heated) mounted on the front head.
- 2-4” air open/spring close valve. Camlock fitings.1-6” discharge valve.
- Hydraulic full opening rear door assembly with 6 heavy-duty wing clamps.
- Double-acting hydraulic cylinder.
- 4” pipe overturn protection and gussets.
- 1-6” exhaust and 1-6” intake
- Full-length hydraulic dump subframe
- Hydraulic reservoir, hydraulic oil filter, and sight glass.
- Spool valve control of rear door, hoist, and vibrator. Separate controls for the wash pump(inside the cabinet).
- Hydraulic vibrator assembly on the bottom of the tank.
- Full-length steel checker plate fenders,
- Tubular handrails, numbered placards, static ground cable, toolbox complete with rain lip.
- 6” or 8” suction boom assembly with 4’ extension-hydraulic powered functions and extension.
- Electronic /Hydraulic pendant controls with 25’ of cable. Boom fully extends to 16’.
- 10pcs of different size Nozzles
- Color as customer specifications.
- Many more options are available on request.
SPECIFICATIONS
| GENERAL INFORMATION | |
| Chassis Model/Make | EQ1070SJ3BDF/Dongfeng |
| Chassis Type | Vacuum Truck Chassis |
| Drive Mode | 4×2 Right Hand Drive |
| Wheelbase | 3308mm |
| Vehicle length | 6.2 m |
| Vehicle width | 2.05 m |
| Vehicle height | 2.65m |
| Tare Weight | 4.93Ton |
| Recommended Loading | 2.3 Ton |
| Gross Vehicle Weight | 7 .36Ton |
| Max Driving Speed | 99KM/h |
| TANK | |
| Tank Capacity | 3 CBM |
| Tank Length | 3.2m |
| Tank Diameter | 1.2m |
| Tank Material | Carbon Steel |
| Tank Material Thick | 5mm |
| Water Tank Volume | 2000Liters |
| Sludge Tank Volume | 1000Liters |
| Flow Capacity | 9.5 m3 /h |
| Suction Depth | >8m |
| Tank Tipping Angle | 45º |
| Suction Time | <5 min |
| Discharge Time | <5 min |
| Water Washing Capacity | 500-800L/min |
| Water Gun Range | 38m |
| Water Flushing Width | 2.5m-3.5m |
| Cleaning Width | > 16m |
| PLUNGER PUMP | |
| Make | Chinese TONGJIE |
| Model | 3D5E |
| Pressure | 16-19Mpa |
| Flow Capacity | 158L/min |
| Spray Flow | 120L/min |
| Grease Capacity | 5L |
| VACUUM PUMP | WEILONG™ PTO Driven Vacuum Pump |
| Vacuum Rate | 80% |
| Pressure | 7000Pa 93% |
| Pump Capacity | 335L/min |
| Speed | 800rpm |
| Power | 5kw |
| ACCESSORIES | |
| Hose Reel | 1 pcs, Reel speed at 0-25m/min |
| Suction Hose | 2pcs ×8 m×125mm diameter |
| Pressure Water Hose | 1pcs × 60m ×19mm diameter |
| Nozzles | Multiple 10pcs different sizes |
| Hose Trays | 1pcs each tank side |
| Access Ladder | Steel fabricated side mounted |
| Mud Guard | Polyethylene |
| Drain Valve | DN50 quick-acting brass drain valve |
| Release Valve | Automatic release valve to avoid the excess pressure limit |
| Open / Spring Close Valve | DN100 spring close valve, aluminum Camlock fittings |
| Exhaust / Intake Valve | DN100 aluminum ball valve |
| Hydraulic Cylinders | Double acting |
| Site Glass | Oil filter and sight glass |
| Fenders | Full-length steel checker plate fenders |
| Tubular Handrails | Steel tube fabricated handrails |
| Toolbox | Toolbox complete with rain lip |
| Electric / Hydraulic Controls | Electronic and hydraulic pendant controls with cable |
| ENGINE | |
| Make | Dongfeng Chaoyang Diesel |
| Model | CY4BK551 |
| Series | 4BK |
| Cylinders | 4 Nos. |
| Fuel Type | Diesel |
| Cylinder Lineup | Vertical in line |
| Displacement | 3.707L |
| Emission Standard | Euro 5 |
| Max Output in kW | 75 |
| Max Output in ps | 102 |
| Max Torque | 280N·m |
| Max Torque at rpm | 1000-2400 |
| Output at rpm | 3000 |
| Engine Type | Vertical in-line, four-stroke, turbocharged inter-cooling, CRDI, SCR |
| CABIN | REALING |
| Cab Type | flat floor all steel constructed |
| Cab Width | 1880mm |
| Passengers Allowed | 3 Nos |
| Seats and Sleeper Line | Front driver / co-driver seats |
| TRANSMISSION | |
| Make | WANLIYANG |
| Model | WLY5 |
| Type | Manual |
| Forward | 5Nos. |
| Reverse | 1 Nos. |
| Casting Material | Steel |
| TIRES, BRAKES, OIL TANKS | |
| Tire Size | 8.25-16 |
| Tire Nos | 6 |
| Brake Type | Air-brake |
| AXLE, SUSPENSIONS | |
| Front Axle Loading | 1500KG |
| Rear Axle Model | 4.5T |
| Rear Axle Loading | 4500kg |
| Leaf Spring Nos | 8/10+7 |
| ABS | Equipped |
