BRIEFS:
Introducing the DONGFENG 30000 Liter Road Sanitation Water Sprinkler Truck, designed to meet the demands of road maintenance and sanitation. With its robust chassis and powerful engine, this vehicle ensures efficient water sprinkling and road cleaning operations. Ideal for new condition applications, left-hand drive, and equipped with an 8X4 configuration, it’s ready to tackle the toughest tasks.
This water sprinkler truck is a versatile and reliable vehicle designed to handle a wide range of sanitation and road maintenance tasks. Its advanced water sprinkler system, impressive reach, and safety features make it an excellent choice for organizations focused on efficient and effective operations.
FEATURES:
Advanced Water Sprinkler System:
- Water Tank Capacity: The 25 cbm (25-ton) tank is designed to hold a substantial volume of water, minimizing the need for frequent refills during operations.
- Tank Material: Crafted from Q235 carbon steel with a thickness of 4 mm, the tank ensures durability and longevity, even in demanding conditions.
- Water Pump: Equipped with a reliable China local brand water pump, this truck efficiently pressurizes and distributes water to meet various sprinkling needs.
- Suction Height: The water pump has an impressive 7-meter suction height, allowing it to draw water from various sources efficiently.
Versatile Sprinkling Functions:
- Front, Side, and Rear Sprinkling: This truck excels at front, side, and rear sprinkling with a width of at least 14 meters. It’s versatile enough to cover a wide area during sanitation and road maintenance tasks.
- Water Cannon: The integrated water cannon offers a remarkable range of over 28 meters, making it suitable for extinguishing fires or controlling dust from a distance.
Safety and Reliability:
- Brake System: The dual-circuit compressed air brake system ensures efficient and safe braking. The emergency spring energy parking brake and auxiliary engine exhaust valve brake provide additional layers of safety.
Comfort and Convenience:
- Spacious Cabin: The single-row cabin is designed for comfort, with room for three passengers. The inclusion of air conditioning enhances the working environment, especially during hot or humid conditions.
Additional Features:
- Entertainment: An AM/FM radio is provided to keep occupants entertained during long working hours.
- Water Hoses: Two water hoses are included, offering flexibility in various applications.
- Color Options: You have the flexibility to choose from optional colors to match your fleet or branding requirements.
SPECIFICATIONS:
| Condition | New condition/Left-hand drive/8X4 |
|---|---|
| Chassis | DONGFENG |
| Curb Weight (kg) | 11,755 kg |
| Loading Weight (kg) | 19,050 kg |
| Gross Weight (kg) | 31,000 kg |
| Wheelbase (mm) | 1,850+4,600+1,350 mm |
| Dimensions (mm) | 12,000 x 2,500 x 3,300 mm |
| Front Loading Capacity | 5 tons |
| Rear Loading Capacity | 10 tons |
| Max. Driving Speed | 90 km/h |
| Clutch | Reinforced diaphragm clutch |
| Brakes | Service Brake: Dual-circuit compressed air brake<br>Parking Brake (Emergency Brake): Spring energy, compressed air operating on rear wheels<br>Auxiliary Brake: Engine exhaust valve brake |
| Steering Gear | Power steering, hydraulic steering with power assistance |
| Tire | Quantity: 12 pcs with one spare tire<br>Specifications: 11.00R20 |
| Transmission | Manual type, 11 Forwards and 1 reverse |
| Cabin | Single row seat, Tiltable. It can accommodate three people. With air conditioner. |
| Engine | Brand: Chaochai |
| Fuel Type | Diesel |
| Power (kW) | 230 kW |
| Horsepower (HP) | 315 |
| Cylinder Number | 6 |
| Emission Standard | Euro 2, Euro 3, Euro 4, Euro 5, Euro 6 |
| Upper | Water Tank:
Capacity (cbm/tons): 25/25<br>Tank Dimension (mm): 8,600 x 2,300 x 1,500 Tank Material: Q235 carbon steel Thickness (mm): 4 Water Pump: China local brand Suction Height: 7M Function: 1. Front Side Rear Sprinkling width ≥ 14m 2. Water cannon range ≥ 28m |
| Remarks | 1. AM/FM radio
2. 2 pcs water hose 3. Color is optional |
