BRIEF:
The DONGFENG 7000 Liter Water Sprinkler Truck is a versatile and efficient vehicle designed to handle various water spraying tasks with precision and reliability. Built on a robust Dongfeng chassis, this truck offers exceptional performance in urban and rural environments. With a focus on safety and functionality, it is the ideal choice for water transportation and sprinkling applications.
The water sprinkler truck combines reliability, efficiency, and versatility, making it an excellent choice for a wide range of water transportation and sprinkling applications. Whether for municipal, agricultural, or industrial use, this truck delivers consistent performance and ensures your tasks are completed with precision.
FEATURES:
- Optimal Dimensions: The truck boasts an overall dimension of 6850mm x 2350mm x 2650mm (mm), providing a well-balanced and maneuverable vehicle that fits comfortably in various settings.
- Impressive Load Capacity: With a Gross Vehicle Weight (GVW) of 11995 kg and a Curb Weight of 4800 kg, this truck offers a substantial load capacity while maintaining stability.
- Dongfeng Reliability: The chassis is manufactured by Dongfeng, a renowned brand known for its durability and dependable performance, ensuring longevity and minimal maintenance.
- Traction Versatility: The 4×2 traction type allows for both left and right-hand drive, enhancing flexibility and adaptability to different driving conditions.
- Spacious Cabin: The flat-head cabin features an original double-row seat design with a four-door passenger compartment. It comfortably accommodates 2 persons in the front row and 3 persons in the back row, ensuring driver and passenger comfort.
- Wheelbase for Stability: A 3800 mm wheelbase contributes to the vehicle’s stability, making it suitable for various terrains and road conditions.
- Durable Tires: Equipped with 8.25R20 tires, this truck maintains excellent traction and stability, even when fully loaded.
- Powerful Engine: The YCY30165-60 engine model meets Euro 4 emission standards (EGR) and delivers an impressive 165 hp of horsepower, ensuring efficient and environmentally friendly operation.
- Smooth Transmission: The 5-forward gears & 1 reverse transmission system ensures seamless gear shifting, enhancing driving performance.
- Reliable Braking System: Featuring drum-type brakes, dual-circuit compressed air brakes, and a power spring brake acting on the rear wheels, this truck offers reliable and safe braking capabilities.
- Auxiliary Brake: The WEVB auxiliary brake system further enhances braking efficiency, particularly during challenging driving situations.
- Axle Strength: With a 2.5T front axle and a 4.8T rear axle, the truck can handle various road conditions and heavy loads.
- Suspension Comfort: The front suspension consists of a 7-leaf spring with a shock absorber for improved ride comfort, while the rear suspension utilizes a 9+6-leaf spring setup.
- Fuel Efficiency: The steel fuel tanker with a 160L capacity ensures efficient fuel management during long-distance journeys.
- Water Sprinkling Capacity: The truck is equipped with a 7 cbm water tanker, making it ideal for tasks such as dust suppression, road cleaning, and irrigation.
- Foam Tanker (Optional): For enhanced firefighting capabilities, an optional foam tanker can be added to the vehicle.
SPECIFICATIONS:
| Attribute | Specification |
|---|---|
| Overall dimension | 6850mm x 2350mm x 2650mm (mm) |
| GVW | 11995 kg |
| Curb weight | 4800 kg |
| Chassis brand | Dongfeng |
| Traction type | 4×2, left/right-hand drive |
| Chassis description | |
| Chassis model | EQ1125SJ8CDC |
| Cab | Structure: flat-head, original double-row seat |
| four-door passenger compartment. | |
| Seat setting: 2 persons in the front row and 3 | |
| persons in the back row. | |
| Wheelbase | 3800 mm |
| Tire specification | 8.25R20 |
| Tire quantity | 6 |
| Engine | Engine model: YCY30165-60 |
| Emission level: Euro 4 (EGR) | |
| Displacement/output: 2970 ml / 121 kW | |
| Horsepower: 165 hp | |
| Gearbox | Model: / |
| Number of gears: 5 forward gears & 1 reverse | |
| Brake system | Type: Drum |
| Service brake: Dual-circuit compressed air brake | |
| Park brake: Power spring brake acting on rear | |
| wheel | |
| Auxiliary brake: WEVB | |
| Axle | Front: 2.5T |
| Rear: 4.8T | |
| Suspension | Front: 7-lear spring with shock absorber |
| Rear: 9+6-Leaf spring | |
| Fuel tanker | Type: Steel fuel tanker |
| Capacity: 160L | |
| Up-parts description | |
| Tanker capacity | Water tanker: 7 cbm |
| Foam tanker: / |
