BRIEF:
The HOWO 12,000 Liter Septic Cleaner Truck is designed for efficient waste management in urban and suburban settings. It combines a robust chassis, powerful engine, and specialized components to facilitate the collection and transportation of bulk waste. This sewage cleaner truck is equipped with a high-capacity water tank, it employs a high-pressure jetting pump system to dislodge debris and sludge from sewers, aiding in thorough cleaning and maintenance.
FEATURES:
- Substantial water capacity: 10,000 liters mild steel tank, accessible via a manhole on top for convenient filling.
- Well-integrated tank-chassis mounting: The water tank is securely mounted on an auxiliary frame, connected to the chassis, ensuring stability during transportation.
- Effortless water filling: Gravity or hydrant filling options for flexibility and ease of use.
- Efficient cleaning mechanism: High-pressure jetting pump, Pratissoli KS40, operating at 140 bar for effective sewer cleaning.
- Flexible hose options: Optional canal hose of 60-120 meters to suit varied cleaning requirements.
- Hydraulic rear hose reel: Allows easy rotation, winding, and rewinding for efficient storage of hoses.
- Multiple jetting nozzles: Equipped with 3-4 varied jetting nozzles to adapt to different cleaning needs.
SPECIFICATIONS:
| Chassis | |
| Size | 7,860*2,490*2,885 (mm) |
| GVW/Curb Weight | 18,000/8,275kg |
| Wheelbase | 4600mm |
| Front/Rear Axle | 7T/16T |
| Tire | 295/80R22.5, 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | WEICHAI /WD615.62/ 266HP/ Euro 2 |
| Transmission | |
| Model | FAST/HW19710 |
| Gears | 9F+1R |
| Operation | Manual |
| Cabin | |
| Driving | HOWO 4×2, Left/Right Hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Upper Body | |
| Water Tank | 10,000Lt, mild steel, manhole on top of water tank |
| Tank-Chassi Mounting | Water tank mounted on auxiliary frame to connect with chassis’ frame |
| Level Gauge | Liquid level gauge installed on water tank |
| Water Tank Filling | Can be filled by gravity or hydrant |
| Water Pump | High pressure jetting pump, Pratissoli KS40, 140bar |
| Canal Hose | 60-120meters optional |
| Rear Hose Reel | Rotated and winding & rewinding by hydraulic |
| Jetting Nozzles | 3-4pcs various jetting nozzles |
