BRIEFS:
The HOWO 6 CBM Vacuum Sewage Suction Truck is a versatile and efficient vehicle designed for the safe and effective removal of sewage and sludge. Equipped with a powerful CUMMINS engine, this truck ensures reliable performance in various environmental conditions. Its 6 CBM vacuum tank, advanced pump system, and high-quality construction materials make it a top choice for sewage suction and transportation.
This vacuum sewage suction truck is a reliable and efficient choice for sewage collection and transportation, with all the necessary features and equipment to perform the task effectively and safely.
FEATURES:
- Cabin: The 2080 Cabin offers a comfortable driving environment with three seats and air conditioning, ensuring operator comfort during long working hours.
- Vehicle Main Dimensions: The truck’s dimensions measure 7000mm in length, 2450mm in width, and 3000mm in height. With a wheelbase of 3360mm, it provides stability and maneuverability.
- Weight: The vehicle’s tare weight is 5240 kg, ensuring efficient fuel consumption and load-carrying capacity. The front axles can carry up to 2400 kg, and the rear axles can handle 4200 kg.
- Engine: Powered by a CUMMINS ISF3.8s3141 engine with a displacement of 3.76L, a compression ratio of 17.2:1, and a torque output of 450 N.m. This 4-stroke, direct injection, 4-cylinder engine with water cooling, turbo-charging, and intercooling offers 141 HP @ 2200 rpm, meeting Euro III emission standards.
- Gearbox: Equipped with a WLY6T51 6-forward & 1-reverse manual gearbox featuring synchromesh technology for smooth gear shifting.
- Steering: The hydraulic steering system with power assistance ensures easy handling and control.
- Tire: Seven 7.50R16 steel tires are included, along with one spare tire for added reliability on the road.
- Fuel Capacity: With a 120L fuel tank, this truck can operate for extended periods without frequent refueling.
- Additional Features: The vehicle comes with essential tools and safety equipment, including a grease gun, a hydraulic jack with a wheel wrench, a tire inflation hose, a 2kg fire extinguisher, two headlights, a reversing buzzer, and plate number lighting. GPS navigation is also included.
- Vacuum Tank Body: The 6 CBM tank features indicator marks for maximum and minimum levels, enhancing operational convenience.
- Tanker Body Material: Constructed from 6mm steel / Q345 high tensile strength steel, ensuring durability and long service life.
- Pump System: The vacuum suction depth reaches 6 meters, and the flow rate allows for filling the sludge tank within 30 minutes.
- Water Hose: A 54-meter hose with an internal diameter of 100mm is provided, made from PVC material in light blue.
SPECIFICATIONS:
| Category | Details |
|---|---|
| Cabin | 2080 Cabin, with three seats and AC |
| Vehicle Main Dimensions | (L x W x H)mm: 7000x2450x3000 |
| Wheelbase (mm) | 3360 |
| Weight in KGS | Tare Weight: 5240 |
| Front Axles Loading | Front Axles Loading Capacity: 2400 KGS |
| Rear Axles Loading | Rear Axles Loading Capacity: 4200 KGS |
| Engine | – Brand: CUMMINS |
| – Model: ISF3.8s3141 | |
| – Displacement: 3.76L | |
| – Compression Ratio: 17.2:1 | |
| – Torque Output: 450 N.m | |
| – Type: 4-stroke direct injection, | |
| 4-cylinder in-line with water cooling, | |
| turbo-charging and inter-cooling | |
| – Horsepower (HP): 141HP@2200rpm, | |
| Euro III | |
| Gearbox | WLY6T51, 6-forward & 1-reverse manual |
| gearbox, with synchromesh type | |
| Steering | Hydraulic steering with power assistance |
| Tire | 7.50R16 steel tire, in total 7 pieces |
| with one spare tire | |
| Fuel Capacity | 120L |
| Others | – With grease gun |
| – With hydraulic Jack with wheel wrench | |
| – With tire inflation hose | |
| – With 2kg fire extinguisher | |
| – With two headlights | |
| – By reversing the buzzer | |
| – With plate number light | |
| – With GPS | |
| Vacuum Tank Body | – Total Volume (m3): 5 CBM, |
| indicator mark on the tank, | |
| for maximum and minimum level | |
| – Tanker Body Material: 6 mm steel | |
| / Q345 high tensile strength steel | |
| Pump | – Vacuum suction depth is 6m |
| – A flow rate allowing the sludge tank | |
| to be filled in a maximum time is 30 | |
| minutes | |
| Water Hose | – 54-meter hose |
| – Internal diameter 100mm | |
| – PVC | |
| – Light blue |
