Brief
The ISUZU High-Pressure Hydraulic Compactor Garbage Truck is made of a standard 4mm thick Q345 manganese steel plate. The bottom tank and hopper are made of thickened steel plates, wear-resistance. With two-way compression, the compression ratio is 3:1 to 6:1. The operating system of the High-Pressure Hydraulic Compactor Truck adopts the German Siemens PLC one-key control system. The hydraulic system adopts the Yangzhou Zhongmei manifold valve, Hefei Changyuan oil pump, hydraulic cylinder of the whole vehicle Hypris (joint venture brand), and Japan Valka sealing ring. Optional garbage bin tippers.
features
Body and Compaction System
The garbage inside the hopper is taken into the body via a sweeper shovel being actuated by two double-acting hydraulic cylinders, and then after being pushed into the body by two double-acting sledge cylinders. The sledge cylinders have min. 24 tones pushing force. The compaction ratio (volumetric) varies between 3:1 to 6:1 according to the characteristic of the garbage.
Lifting Devices
Can lift standard 120/240/770 and 1100 liter. steel and plastic containers (EN 840-2 standard). The lifting weight capacity is 800 kg ( All lifting device parts are made of rigid steel ).
Safety Props
The tailgate is provided with safety props between the body and the tailgate for safety purposes during maintenance or cleaning.
Accessories
Foldable Operator Steps on both sides
Hand grips, and hand bars on both sides for operators
One Nos Working light in a suitable place of the tailgate
One Nos Rotating beacon in a tailgate
The operating sticker is in the necessary places.
The rearview camera is located on the tail gate and the 7” screen is on the truck cab.
Operating and maintenance manuals in English
Side guards where applicable
Painting
All parts and compartments are primers painted separately. The painting process is done in steps:
Sand blasting and Shock primer for all parts & surfaces.
Epoxy paint for all parts & surfaces
Final acrylic paint in Orange RAL color
specification
| Engine | |
| Make/Model | ISUZU/4HK1-TCG61 |
| Type | Diesel Engine |
| Engine System | 4 Stroke, High-Pressure Common Rail, Inter-cooling Turbo-Charged, 4 Cylinders |
| Output Power@ speed | 189hp@2600rpm |
| Displacement | 5.193L |
| Max. torque @ Speed | 507N.m@1600-2600rpm |
| Emission standard | Euro 6 |
| Transmission | |
| Gears | 6F+1R |
| Operation | Manual |
| Cabin | |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Body and Compaction System | |
| Capacity | 8CBM |
| Material | Weather-resistant steel, high corrosion resistance |
| Design | Sealed leakage proof |
| Compaction Ratio | 1:2 – 1:3 |
| Containers Lifting Devices | High capacity articulated lifter works in a minimum of two stages by four double effects hydraulic cylinders to ensure the lifting and lowering of containers smoothly.
Lifting weight capacity not less than 800 kg. |
| Control System | Equipped with three sets of automatic, manual control, and wireless remote control modes, it can control the operation of the garbage truck in the driver’s cab, the middle of the garbage, and the rear of the garbage. |
