WHY ORDER YOUR TANKS FROM CSCTRUCK?
A subsidiary of CRCC. 700,000sqm Facilities. Leading Special Truck Factory China. Top Quality and Bargain Prices.
If you are Choosing the best Supplier for Vacuum Tank Pumper Truck?
Just call us. We will help you equip your trucks.
GENERAL INFORMATION:
The Truck is from the manufacturers’ standard range of production and current supply, brand new, and guaranteed from all types of defects. We also accept custom-designed structured tank trucks. All equipment and parts are fully assembled with standard fittings, tested, ready for immediate use, and suitable for continuous operation in ambient conditions at altitudes up to 3000 meters and within the temperature range from –40C to +40C.
FEATURES COMPONENTS FOR TANK MODELS
SPECIALIZED UNITS
● All tanks are made to GB18564 Road Tanker Transportation standards.
● Sewage Tank Interior coated anti-corrosion paint of epoxy and polyurethane.
● Level indicator. Checking Windows. Tire carriers.
● Inside Partitions to avoid Splash Over and Swinging.
● Installed on unique cab and chassis
● Manually controlled, 4″ and 5″ Suction valves with quick coupling.
● Optimized length, heights, and width to be stored in your building
● Narrow and extra wide tanks available.
● Operating and maintenance manuals and CDs in the English language
What Options Fit Your Needs
● Import Vacuum Pump
● Rotary Suction Boom
● Remote Control Unit
● Extension Suction Connector
● Tank Self Cleaning Device
● Pneumatic Tube Cleaner
● Specifically Designed For Liquid Bio-Waste From Sewerage Grease Trap Environments.
*All of our tanks are fully customizable with an array of different component options available. Below are some of our standard customizations that are available. If you are looking for a more specific component for your tanker, please contact us to discuss your options. And get the details from the Seller
PARAMETERS
| TANKER ASSEMBLY | Steel Round Tank. |
| Capacity Gross | 18,000liters |
| Capacity Nett | Dependent on Ullage |
| Tank Vessel Material | Super Strength Carbon Steel |
| Tanker Vessel Thickness | 5mm |
| Pump | PTO Driven Vacuum Pump |
| Fully Loading Time | < 5 min |
| Depth Suction | 8m |
| Emptier Time | <4 min |
| Air Pipe Diameter | 50mm |
| GVW | 25000kg |
| Vehicle Weight | 13005kg |
| Loading(CN) | 11800kg |
| Tanker Size | Length 5500mm × Diameter 2000 mm |
| Vehicle Dimension | 9590×2500×3800 mm |
CHASSIS RECOMMENDATION
| Chassis Make | Dongfeng KL |
| Wheelbase | 4350+1350mm |
| Front Axle | 7T |
| Rear Axle | 10T+10T |
| Transmission | FAST 9JS119T-B 9 Speed forward+ 1-speed reverse |
| Brake | Dual Line Air Brakes |
| Engine | Dongfeng Cummins C245 33 245hp, |
PICK UP A CHASSIS
We offer oil tank trucks on a variety of chassis including ISUZU, HINO, UD, JAC, SINOTRUK, SHACMAN, BEIBEN, and DONGFENG, available on any commercial chassis.
*Please scroll down to see this Municipal Vacuum Tank Truck chassis inventory, you may optionally choose above different brand of chassis for one of your tanks, or need a new tank for one of your truck chassis for mounting this Municipal Vacuum Tank. There is the one you need.
TRAINING
Operating and maintenance training for the buyer personnel is provided in our factory for 2 days till it’s believed all necessary details are shared. If it’s requested, our technical team (consisting of 2 technicians) could also travel to the buyer’s homeland in order to provide this training. In this case, all transportation and accommodation costs ( visas – plane tickets – airline fees – motorway transportation –hotel room – meals, etc.) on the route of “Hubei China – Buyer’s Field – Hubei China” is undertaken by the buyer. Normally, total training time doesn’t get longer than 2 days with all necessary conditions being met.
