Introducing the DONGFENG 14,000L water jetting truck from CSCTRUCK. This powerful truck is designed to efficiently and effectively clean streets, sidewalks, and other public areas. Here’s what you need to know about this impressive machine:
Chassis:
The DONGFENG 14,000L water jetting truck is built on a sturdy chassis that measures 8,250mm x 2,500mm x 2,950mm. It has a GVW/Curb Weight of 18,000kg/10,000kg and is powered by a diesel engine made by DONGFENG/CUMMINS that delivers 270hp and is Euro 3 compliant. It has a 10-speed manual transmission made by FAST, with 10 forward gears and 2 reverse gears.
Cabin:
The cabin of the DONGFENG 14,000L water jetting truck is a DONGFENG KR 4×2 Day Cab with left-hand drive. It is made of steel construction and has a single-row and flat design. It can accommodate up to 3 passengers.
Body System:
The tanker of the DONGFENG 14,000L water jetting truck is made of stainless steel 304 and has a capacity of 14,000L. It has a tank body thickness of 6mm and is equipped with front flushing, side spraying, rear sprinkling nozzles, and a platform with a water cannon and water gun. The water cannon can be rotated 360 degrees and the water flow can be adjusted to heavy, medium, light rain, drizzle, and mist.
Performance:
The DONGFENG 14,000L water jetting truck has an impressive performance that makes it ideal for cleaning public areas. It has a spraying width of ≥14m and a canon range of ≥35m. It can also suction water from a depth of over 7m and has a full tank suction time of fewer than 15 minutes.
Equipment:
The DONGFENG 14,000L water jetting truck comes equipped with a stainless steel self-priming sprinkler pump that has a flow rate of 60m³/h and a lift height of 90m. It also has a self-priming height of 7m. Other parts included are a self-flow valve, a fire joint, and 2 water pipes.
In conclusion, the DONGFENG 14,000L water jetting truck from CSCTRUCK is a reliable, high-performance machine that is perfect for cleaning streets, sidewalks, and other public areas. Its powerful engine, sturdy chassis, and impressive equipment make it a must-have for any municipality or public works department.
| Chassis | |
| Size | 8,250×2,500×2,950mm |
| GVW/Curb Weight | 18,000kg/10,000kg |
| Wheelbase | 4,700mm |
| Front/Rear Axle | 6.5/11.5T |
| Tire | 11.00R20 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | DONGFENG/CUMMINS/ISDe270 30/270hp/Euro 3 |
| Transmission | |
| Make/Model | FAST/10JS90A |
| Gears | 10F+2R |
| Operation | Manual |
| Cabin | |
| Driving | DONGFENG KR 4×2 Day Cab, Left-hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Body System | |
| Tanker Capacity | 14,000L |
| Shape | |
| Material | Stainless steel 304 |
| Thickness | Tank Body 6mm |
| Performance | |
| Spraying Width(m) | ≥14m |
| Canon Range(m) | ≥35m |
| Suction Height | >7m |
| Full Tank Suction Time | <15 minutes |
| Equipment | |
| Sprinkler Pump | Front flushing, side spraying, rear sprinkling nozzle, and platform with water cannon and water gun.
The water cannon can be rotated 360 degrees. The water flow can be adjusted to heavy, medium, light rain, drizzle, and mist. |
| Type | Stainless steel self-priming sprinkler pump |
| Flow Rate | 60m³/h |
| Lift Height | 90m |
| Self-priming Height | 7m |
| Other Parts | |
| Include | Self-flow valve 1pc; Fire joint 1pc; Water pipe 2pcs |
