features

Suction Device

Two kinds of suction cups for options (single-tube suction cup and double-tube rolling sweep). In order to ensure the best cleaning effect, after the suction nozzle supports the roller on the ground, the gap between the bottom edge and the road surface is maintained at about 5-10mm.

Cleaning Device

Composed of left front and right front cleaning devices and left rear and right rear cleaning devices on both sides of the body. The oil cylinder controls it to “retract and put down” and has the function of anti-collision and avoidance.

Hydraulic System

Composed of oil pump motor, hydraulic cylinder, relief valve, solenoid valve, throttle valve, hydraulic control check valve, back valve, manifold block, manual pump, hydraulic oil tank, oil pipe, etc.

Sprinkling System

Composed of stainless steel water tank, water filter, water pump, ball valve, three-way ball valve and nozzle.

Operating System

Mainly in the chassis cab to control the conversion of various functions by operating buttons, easy to operate.

Debris and water Tank

It is a sealed type, with a welded structure of skeleton and stainless steel plate, and the back door can be opened for self-unloading.

specification

Overall Size	7100×2230×2750 (mm)
Wheelbase	3800 mm
GVW	7360 kg
Vehicle Weight	5040 kg
Chassis Make/ Model	DONGFENG/ EQ1070
Chassis Engine	CY4BK
Chassis Engine Power	75 hp
Auxiliary Engine	Jiangxi Isuzu JX493ZG
Auxiliary Engine Power	57Kw
Cab	Sleeper Cab
Transmission	5 speed forward manual
Front Axle Rating	2640 kg
Rear Axle Rating	4720 kg
Brake	Air brake, Exhaust brake ABS
Steering	Hydraulic assistance
Air-conditioning	Heating & Cooling
Tire	7.00-16 6+1 nos
Max. Sweeping Swath	2800～3000 mm
Sweeping Capacity	60000 m2/h
Sweeping Speed	3～25 km/h
Sweeping Efficient Ratio	≥96 %
Suction Debris	95 mm
Air Speed	2900 RPM
Negative Pressure	2.94 Kpa
Hopper Volume	4.2 m3
Water Tank Volume	1.2 m3
Hope Dumping	≥45°
Gradeability	≮30 %
Turning Radius	1≯20 m
Brake Distance (full loaded)	≤10 m @ 30km/h
Max Drive Speed	99 km/h
