specification
|
General Information |
Make & Model |
CSCTRUCK |
|
Date of Manufacturing |
2022 |
|
|
Country of Origin |
China |
|
|
Truck Unit’s Status |
Brand new |
|
|
CSCTRUCK’s Status |
Established and reputable |
|
|
Drive Type |
4×2 Left Hand Drive |
|
|
Overall Dimension (L x W x H) |
5755×2070×2450(mm) |
|
|
Gross Vehicle Weight |
7,300kg |
|
|
Curb Weight |
5,030kg |
|
|
Wheelbase |
3,360mm |
|
|
Max. Speed |
95km/h |
|
|
Chassis Designed |
ISUZU KV100 |
|
|
Cabin |
Hydraulic power steering type. 1 driver+2 passengers |
|
|
Drive wheel(Tires ): |
2+4 and one spare (total 7 wheels) |
|
|
Tire Specification |
700R16 |
|
|
Tank Capacity: |
5M3 |
|
|
Engine |
Make / Model |
ISUZU / 4KH1CN5LS |
|
Country of Origin |
China |
|
|
Type |
4 cylinders in line, 4 strokes direct injection, water cooling, Intercooler Turbocharged |
|
|
Air Intake |
Turbo-charged |
|
|
Fuel |
Diesel |
|
|
Cooling System |
Water cooling system |
|
|
Displacement |
2.999L |
|
|
Nominal Power |
98HP (72kw) @ 3400rpm |
|
|
Peak Torque |
220N.m@1700rpm |
|
|
Emission Standard |
Euro V |
|
|
Max. Rotated Speed |
1700rpm |
|
|
Bore x Stroke |
Φ95.4×104.9mm |
|
|
Used |
Engine is used to power the remaining system through a hydrostatic drive and all components through a hydrostatic drive. |
|
|
Electronics |
The engine electronics accept a remote variable throttle for stationary operation through transmission mounted PTO and transfer case-driven PTO equipment. The air cleaner is to be manufacturers recommended duel air. Air restriction gauge, dash mounted or approved equal. |
|
|
Included |
Turbo, injectors, starter, and alternator. Automatic engine shutdown system with low oil pressure, high coolant temperature, and low coolant level. |
|
|
Clutch and Transmission
|
Operation of Transmission |
Manual |
|
Hydraulic, Cltuch Actuation |
Hydraulic operating with air assistance |
|
|
Number of Speeds |
5F+1R |
|
|
Fuel Type of Transmission |
Diesel |
|
|
Model/Make of Transmission |
ISUZU/ MSB |
|
|
Brakes and Tyres |
Brakes |
Hydraulic-pneumatic assisted, dual circuit, pressure-air, air dryer. |
|
Brake Type |
Drum brake with ABS |
|
|
Tire Size |
7.00R16
|
|
|
Total Number of Wheels with Spare |
6 wheels and 1spare |
|
|
Service Brake |
Dual circuit pressure-air brake acting on wheels of all axles. |
|
|
Emergency Brake |
Spring type, acting on wheels of rear axles. |
|
|
Parking Brake |
Spring type, acting on wheels of rear axles. |
|
|
Auxiliary Brake |
Engine brake, flap type exhaust brake. |
|
|
Suspension |
Front Type |
Heavy duty leaf springs with telescopic shock absorbers at front |
|
Rear Type |
Heavy duty leaf springs |
|
|
Cab |
Type |
4 point full-floating air suspension, with 1 sleeper |
|
Installed |
Air conditioned, audio system, rear view camera, rear motion buzzer |
|
|
Passengers Allowed |
2+1 |
|
|
Color |
Based on requirement |
|
|
Safety Belts |
Installed |
|
|
Axles |
Loading Capacity of Front |
2,580kg
|
|
Loading Capcity of Rear |
4,720kg |
|
|
Electrical System on Chassis |
Working Voltage |
24V, negative grounded |
|
Starter |
24V, 7.5kw |
|
|
Alternator |
3-phase, 28V |
|
|
Battery Type |
2 x 12V -165A.H |
|
|
Working Parameters |
Max. Sweeping Width（m） |
2.8-3 |
|
Working speed（Km/h） |
3-25 |
|
|
Max Sweeping Capacity（m2/h） |
6000 |
|
|
Max suction for garbage density limited 2g/cm 3（mm） |
lESS 100 |
|
|
Tilt Angle（°） |
≥50 |
|
|
Tanker Capacity（m3） |
5 |
|
|
Dust Tanker Capacity（m3） |
4 |
|
|
Water Tanker Capacity（m3） |
1 |
|
|
Fuel Consumption |
Driving（L/100km） |
≤12 |
|
Fuel Consumption（L/H）（Working Speed @8km/H）（L/1000m2） |
2.6 |
|
Ancillary Engine |
Model |
JX493ZG |
|
|
Type |
Four stroke water cooing ,direct injection diesel engine |
||
|
Power |
57Kw |
||
|
Max output speed |
2400r/min |
||
|
Fuel |
0# light diesel same with chassis truck engine |
||
|
Air Blower |
Type |
High pressure , centrifugal ,sweeping truck specific used blower |
|
|
Working Speed |
2600～2900r/min |
||
|
Driving Mode |
Drive by ancillary engine , automatic clutch, V belt powered |
||
|
Hydraulic System |
Type |
Open type, hydraulic control |
|
|
Main Components |
Gear pump, Gerotor motors, Hydraulic cylinders, solenoid valves, IC, manual pump etc. |
||
|
Oil Pressure Relief |
14MPa |
||
|
Hydraulic oil level |
In 1/2～2/3 position |
||
|
Hydraulic oil |
Working temperature @-30℃～5℃,hydraulic oil is L-HV32 Working temperature @5℃～25℃,hydraulic oil is L-HM46 Working temperature @25℃～40℃,hydraulic oil is L-HM68 |
||
|
Oil Tank Capacity |
60L |
||
|
Hydraulic Pump |
Type |
Gear pump |
|
|
Displacement |
10 ml/r |
||
|
Pressure |
14 MPa |
||
|
Max speed |
3000 r/min |
||
|
Hydraulic Motor |
Type |
Gerotor motors |
|
|
Displacement |
160 ml/r |
||
|
Pressure |
14 Mpa |
||
|
Max speed |
385 r/min |
||
|
Washing system |
Main component |
Electric water pump、water filter, nozzle, water tanker etc. |
|
|
Electric System |
Composed |
working with chassis electric system ,and Ancillary Engine electric system power supplied with two modules of battery |
|
|
Voltage |
12V |
||
|
Battery Request |
12-80A.h |
||
|
Sweeping System |
Type |
Four disc typed brooms equipped between front and rear axle , symmetric in right and left side of the truck drive by gerotor motors. |
|
|
Sweeping disc diameters |
Φ800mm |
||
|
Sweeping disc speed |
High speed：110r/min Medium ；80 r/min low：60 r/min |
||
|
Sweeping disc tilt angle |
Front tilt 4°～6° right and left tilt 2°～4° 6°～10° |
||
|
Suction Nozzle |
Type |
U shaped servo Suction nozzle |
|
|
Suction hose diameters |
Φ190mm |
||
|
Nozzle ground clearance |
5～10mm |
||
