Vehicle model

AUMARK-C38

Cabin

Single   row/W1995/right rudder

Overall dimensions   (LxWxH)mm

6725×2100×2280

Wheelbase(mm)

3800

Curb weight(kg)

3305

Gross vehicle weight（kg）

6500

ENGINE

F3.8s3141/EuroⅢ/3.76L/105kW

Gearbox

TS55

Front axle

2.5T

Rear-axle

6.0T

Front suspension/Leaf spring number

9

Rear suspension/Leaf spring number

11+7

Wheels and tyre size

6+1(8.25R16)

Effective   volume of box body (M3)

6.5

The volume of clean water tank (L)

170-180

Sewage   tank volume (L)

330-360

High   pressure cleaning water flow (L/min)

9.83

Operation method

Electronic   control + manual control

Operating   time of turning frame (s)

≤25

Waste discharge time (s)

≤30

Hang barrel way

1120L+240L standard plastic trash can

The compartments body

Stainless steel
