BRIEF

The ISUZU KV100 Road Sweeper Truck is a multifunctional road sweeper and scrubber truck designed for high-efficiency road cleaning and dust suppression. Built on a reliable Isuzu 4KH1 chassis, it is powered by an Isuzu diesel engine (97 kW / 88 kW) and equipped with a dedicated Cummins 103 kW auxiliary engine for the working system. The vehicle integrates sweeping, high-pressure washing, curb cleaning, low-pressure flushing, and vacuum suction into one compact unit, improving cleaning efficiency while reducing operating costs.

The truck features a 4 m³ clean water tank and a 5 m³ stainless steel debris/wastewater tank, offering strong corrosion resistance and long continuous operation time. With a maximum sweeping width of 2.8 m and a cleaning capacity of up to 56,000 m²/h, the CLW5080TXSQ6 delivers excellent cleaning performance for both urban and industrial environments.

Its advanced working system combines two central disc brushes, a wide suction nozzle, and high-pressure spray bars to loosen debris, wash the surface, and vacuum wastewater simultaneously, leaving roads clean and dust-free in a single pass. The truck also features automatic obstacle-avoidance side spray bars, a hydraulic floating suction nozzle, and a PLC intelligent control system that allows operators to control all cleaning functions directly from the cab. The ISUZU sweeper truck is ideal for applications including urban roads, highways, industrial parks, construction sites, airports, ports, tunnels, and mining areas.

FEATURE

High-Efficiency Sweeping & Cleaning

• Maximum sweeping width: 2.8 m — Covers large areas efficiently and reduces the number of cleaning passes.
• Maximum cleaning capacity: 56,000 m²/h — Ideal for high-productivity municipal and industrial cleaning operations.
• Adjustable sweeping speed: 5–20 km/h — Balances cleaning performance and operational efficiency for different road conditions.
• Maintenance cleaning speed: 15–20 km/h — Enables rapid daily road maintenance.

Advanced Tank Design

• 4 m³ clean water tank + 5 m³ debris/wastewater tank — Supports long continuous working hours.
• Stainless steel debris tank — Corrosion-resistant, durable, and easy to maintain.
• Separate tank structure — Allows simultaneous wastewater discharge and water refilling without stopping operations.
• Hydraulic tank lifting and dumping system — Enables fast, convenient unloading and internal cleaning.

Integrated Sweeping & Washing System

• Two central disc brushes + wide suction nozzle + high-pressure spray bars — Combines sweeping, scrubbing, washing, and vacuum recovery in one operation.
• Built-in high-pressure spray bar — Delivers uniform water coverage without dead angles.
• Left and right V-shaped side spray bars — Direct debris and wastewater efficiently toward the suction nozzle.
• Single-pass cleaning system — Leaves road surfaces clean, dry, and dust-free.

Intelligent Obstacle Avoidance & Safety

• Automatic obstacle avoidance system — Side spray bars automatically retract when hitting obstacles and return to working position afterward.
• Hydraulic floating suction nozzle — Automatically adapts to uneven road surfaces for improved cleaning performance and reduced wear.
• Enhanced operational safety — Reduces component damage and improves reliability in urban environments.

Intelligent Control System

• PLC programmable control system — Integrates electric, hydraulic, and pneumatic systems into one intelligent platform.
• Cab-controlled operation — Operators can control sweeping, spraying, brushes, and suction without leaving the cab.
• User-friendly interface — Simplifies operation and reduces driver fatigue.

Reliable Chassis & Power System

• Isuzu 4KH1 diesel engine (97 kW / 88 kW) — Fuel-efficient, durable, and easy to maintain.
• Cummins 103 kW auxiliary engine — Provides stable power for the sweeping and scrubbing system.
• Optimized chassis balance — Ensures stable operation and driving comfort.
• Heavy-duty design — Suitable for continuous municipal and industrial cleaning tasks.

SPECIFICATION

CATEGORY	ITEM	PARAMETER
General	Drive Type	4×2
	Overall Dimensions (L×W×H)	7050×2220×2700 mm
	Wheelbase	3815 mm
	Gross Vehicle Weight (GVW)	8,280 kg
	Curb Weight	6,900 kg
	Front / Rear Overhangs	1120 mm / 2150 mm
Cab	Model	3X
	Number of Seats	3
	Instrument & Controls	Air Conditioner/Center Lock/Multifunctional Steering/Power Window
Engine	Make	ISUZU
	Model	4KH1CN6LB
	Horsepower	88kW (120HP)
	Engine Type	4 Cylinder in-line, diesel engine
	Emission Standard	EURO 6
	Displacement	2.999 L
	Fuel Tank	100 L
Transmission	Make/Model	ISUZU/MSB-5MT
	Gear Numbers	5F+1R
Axle	Front Axle Rating	3,000 kg
	Rear Axle Rating	5,280 kg
Chassis	Type	U-profile parallel ladder cold riveted cross
	Suspension	Mechanical, Semi-elliptic Leaf Springs 6/6+6
Tyre	Size	7.50R16LT 14PR
	Nos	6+1
Superstructure	Sweeping Width	2.8 m
	Sweeping Speed	5-20 km/h
	Maximum Cleaning Capacity	56000 m²/h
	Fresh Water Tank Capacity	4 m³
	Dustbin Capacity	5 m³
	Discharging Method	Hydraulic Tilting Discharge
	Discharging Angle	≥43°
	Auxiliary engine	Cummins 103 kW
