SUMMARY:
The DFAC 10 CBM Sewage Suction Truck is a highly efficient and reliable solution designed for sewage management and suction operations. With its well-engineered chassis, powerful engine, and advanced upper equipment parameters, this truck offers the capacity to handle sewage collection and transportation tasks effectively. Its user-friendly features and compliance with emission standards make it a versatile choice for municipalities and sanitation companies engaged in sewage management and waste disposal.
The Sewage Suction Truck combines an efficient design, powerful engine performance, and optimized upper equipment to offer a reliable solution for sewage collection and transportation needs. Its adherence to emission standards and user-centric features make it a valuable asset for organizations engaged in urban sanitation and waste management.
FEATURES:
- Drive Mode: The 4X2 drive mode ensures optimal maneuverability and control, making it suitable for urban and suburban sewage collection tasks.
- Wheelbase: With a wheelbase of 3308mm, the truck achieves a balance between stability and agility during sewage suction and transportation activities.
- Type: As a dedicated “Sewage Suction Truck,” this vehicle is purpose-built for efficient and sanitary sewage collection and disposal.
- Body Size: The spacious body measures 5.995×2.01×2.5 meters, accommodating a substantial volume of sewage for efficient transportation.
- Weight Capacities: The truck boasts a gross weight of 7.36 tons and a rated weight of 3.53 tons, ensuring its capability to manage varying sewage loads.
- Front/Back Overhang: With a front/back overhang of 1.055/1.632 meters, the truck maintains accessibility and maneuverability in congested areas.
- Front/Rear Wheelbase: The front wheelbase of 1525mm and rear wheelbase of 1498mm contribute to stability and control while operating in different environments.
- Engine Parameters: Powered by the Chaoyang CY4BK461 engine with a displacement of 3.707L, the truck delivers a maximum output power of 95kW (129 hp) at a rated speed of 2600rpm.
- Emission Standard: The engine complies with China VI emission standards, reflecting its commitment to environmental sustainability.
- Fuel Type: Operating on diesel fuel, the truck strikes a balance between fuel efficiency and power delivery for sewage management tasks.
- Upper Equipment Parameters: The vehicle announcement code 5070GXED6 identifies this truck’s optimized upper equipment configuration for effective sewage suction and transportation.
- Upper Brand: The upper equipment is attributed to the renowned CSCTRUCK Brand, synonymous with quality and performance.
- Tank Body Size: Featuring a tank body measuring 3.5×1.65×1.2 meters, the truck accommodates substantial sewage volume for efficient transportation.
- Tank Volume: With a tank volume of 4.63m3, the truck maximizes its sewage carrying capacity, reducing the need for frequent unloading.
- Transmission Parameters: Equipped with a Wanliyang 5-speed transmission model, the truck ensures smooth gear transitions and efficient power delivery.
- Chassis Parameters: Built on the robust Dongfeng Duolika chassis from the Duolika D6 series, model EQ1075SJ3CDF, this truck ensures durability and longevity.
- Number of Spring Leaves: The chassis incorporates 6/6+5 spring leaves, contributing to stability and comfort during sewage collection routes.
- Tires: The truck is equipped with 6 tires, adhering to specifications 7.00R16, ensuring traction, stability, and durability during sewage management tasks.
SPECIFICATIONS:
| Drive Mode | 4X2 |
| Wheelbase | 3308mm |
| Type | Sewage Suction Truck |
| Body Size | 5.995×2.01×2.5 meters |
| Gross Weight | 7.36 tons |
| Rated Weight | 3.53 tons |
| Front/Back Overhang | 1.055/1.632 meters |
| Front/Rear Wheelbase | Front: 1525mm; Rear: 1498mm |
| Engine Parameters | |
| Engine Model | Chaoyang CY4BK461 |
| Displacement | 3.707L |
| Max Output Power | 95kW |
| Max Horsepower | 129 hp |
| Emission Standard | EURO 2, EURO 3, EURO 4, EURO 5 |
| Fuel Type | Diesel |
| Rated Speed | 2600rpm |
| Upper Equipment Parameters | |
| Vehicle Announcement | 5070GXED6 |
| Upper Brand | CSCTRUCK |
| Tank Volume | 4.63m3 |
| Transmission Parameters | |
| Transmission Model | Wanliyang 5-speed |
| Number of Gears | 5 |
| Chassis Parameters | |
| Chassis Brand | Dongfeng Duolika |
| Chassis Series | Duolika D6 |
| Chassis Model | EQ1075SJ3CDF |
| Number of Spring Leaves | 6/6+5 |
| Tires | |
| Number of Tires | 6 |
| Tire Specifications | 7.00R16 |
