BRIEFS:
The HOWO 20 CBM Fecal Suction Sewage Truck is a high-performance vehicle designed for efficient fecal and sewage removal. With a robust engine, spacious cab, and a large-capacity tank, this truck is engineered to handle demanding sanitation tasks. It provides an impressive vacuum system, sturdy construction, and powerful performance, making it an ideal choice for municipal and industrial applications.
This fecal suction sewage truck is an essential addition to any municipal or industrial sanitation fleet. Its robust design, impressive power, and efficient waste handling capabilities make it an indispensable tool for sanitation professionals.
FEATURES:
- Impressive Power: Equipped with a WD615.87 engine boasting 290HP, this truck delivers exceptional power for various operations.
- Spacious and Comfortable Cab: The HW76 cab provides a comfortable and ergonomic workspace with air conditioning, making long working hours more manageable.
- High Load Capacity: Capable of carrying up to 25,000 kg when fully loaded, this truck can handle substantial sewage and fecal waste volumes.
- Superior Handling: The ZF8098 hydraulic steering system with power assistance ensures smooth and precise maneuvering.
- Exceptional Vacuum System: Featuring a vane pump imported from Italy, the vacuum system can generate a maximum vacuum of 90%, allowing efficient suction of waste materials.
- Large Suction Tank: The 16m³ tank provides ample storage for collected waste, and its substantial dimensions (φ1,900 x 6,200) enable efficient loading and unloading.
- Deep Suction Capability: The truck’s suction tube (φ100mm) reaches depths of at least 8 meters to access hard-to-reach waste.
- Reliable Construction: Built with sturdy materials and a tank thickness of 6mm, this truck can withstand the rigors of sanitation operations.
- Quick Discharge: The rear tank door opens up to 60°, and the tank lifting angle of 30° facilitates easy and efficient waste disposal.
- High Pumping Speed: The vacuum pump has a remarkable speed of 318m³/h, allowing for swift and effective waste removal.
- Optimized for Safety: The ABSOLUTE Value: 10 vacuum and 90% Percentage vacuum system ensures safe and secure operation, reducing risks associated with waste handling.
SPECIFICATIONS:
| Parameter | Details |
|---|---|
| Weight Parameter | |
| Curb Mass (kg) | 11,030 |
| Full Loaded Mass (kg) | 25,000 |
| Dimension Parameter | External Size (mm) |
| Length (mm) | 9,850 |
| Width (mm) | 2,496 |
| Height (mm) | 3,680 |
| Wheel Base (mm) | 4,325 + 1,350 |
| Min Ground Clearance (mm) | 314 |
| Performance Parameter | |
| Max Speed (km/h) | 102 |
| Economic Speed (km/h) | 82 |
| Max Grade Ability (%) | 35 |
| Min Turning Diameter (m) | 19 |
| Vehicle Configuration | |
| Cab | HW76, 1 sleeper, with air conditioner |
| Engine Model | WD615.87, 290HP EURO 2, EURO 3, EURO 4, EURO 5 |
| Engine Type | 6 cylinder in-line, 4 stroke, inter-cooling, turbo-charging |
| Net Power (kW) / Speed (r/min) | 213 / 2,200 |
| Max Torque (N.m) / Speed (r/min) | 1,350 / 1,100 – 1,600 |
| Steering System | ZF8098, hydraulic steering with power assistance (left-hand drive) |
| Fuel Tank (L) | 300 |
| Tires | 12.00-20 nylon tires, 11 units |
| Suction Tank Parameter | |
| Overall Dimension of Tank | φ1,900 x 6,200 |
| Effective Volume of Tank | 16m³ |
| Diameter of Suction Tube | φ100mm |
| Suction Depth | ≥8m |
| Opening Angle of Rear Tank Door | 60° |
| Tank Lifting Angle | 30° |
| Vacuum Pump Type | Vane pump imported from Italy |
| Pumping Speed | 318m³/h |
| Rated Speed | 1,300rpm |
| Max Vacuum | Absolute Value: 10, Percentage: 90% |
