Engine

Make/Model

Chaochai/CY4102-CE4F

Type

Water-cooled, intercooling turbocharging system, four-stroke cycle diesel

Horsepower

99hp (73kw) @2800rpm

Torque

650(N.m)/ 1300～1500 (rpm)

Displacement

3856ml

Emission Standard

Euro 4

Cabin

Type

Day cabin, Full steel skeleton structure, covered with double layer steel plate.

Equipment

With inner A/C; with low temperature starting system.

Chassis Frame

Type

Light-duty all strong steel constructed frame to be reinforced with cross members

Transmission

5 speed forward and 2 speed reverse

Steering

Power assistance steering, Left hand control

Axles

Front/ rear Axle: 2000kg/ 5000kg

Refuse Collecting Body

Capacity

5CBM

Material

Q235 carbon steel,thickness 5mm for bottom, 4mm thick for side body

Ejector

Type

Heavy duty ejector made of U beams ,covered by 4mm steel sheets

Control

Powerful-double acting hydraulic cylinder moves the ejector forward and backward.

Side Loading Mechanism

Work

Operates by means of two (02) hydraulic cylinders.

Availability

Could be adapted for many refuse containers.Two side loading mechanisms available.

Hydraulic System

Work

Hydraulic gear pump connected to the P.T.O.

Maximum Pressure

Nominal 22MPа settled.

Equipment

Hydraulic tank with filters lids, temperature gauge and level indicator, oil tank are standard equipped.
