ISUZU 18T Hook Lifter Garbage Truck

Chassis
Size	8,96025403040mm
GVW/Curb Weight	25,000/11,100kg
Wheelbase	4650+1300mm
Front/Rear Axle	9T/16Tx2
Tire	12.00R20 10+1 tires
Engine
Type	Diesel
Make/Model	ISUZU/6HK1-TCH/300hp/euro5
Transmission
Make/Model	FAST/9JS119TA
Gears	9F+1R
Operation	Manual
Cabin
Driving	ISUZU FVZ 6×4 Night Cab, Left-hand Drive
Type	Steel construction, Single Row, Flat
Passenger No.	3
Hook Lift System
Lifting Capacity	18 Ton
Material	Q235B Carbon Steel, 4mm Side, 5mm Bottom
Lifting Time	50s
Discharging Time	50s
Tipping Angle	50°
Locking	2 side locking system
Control System	Manual control, and smart control as options
Hydraulic System	Branded multi-way valve, cylinders
Include	Underframe, linkage frame, fixed arm, hook arm, locking system, hydraulic system.

Certification	ISO9001:2015
Chassis Truck	ISUZU
Color	Customized Color
Condition	New
Delivery Time	50 Days
Drive Mode	6×4
Country of Origin	Made in China
Customized	Yes
Emission Standard	Euro V
Fuel Type	Diesel
Intercom	CIF
Main Markets	Africa, Eastern Asia, Mid East, North America, Oceania, South America, Southeast Asia
Packaging Details	Waxed
R&D Capacity	ODM, OEM, Own Brand(CSCTRUCK)
Shipping Vessel	Bulk Shipment, Container Shipment, Flat Rack, FR Container Shipment, RORO Shipment
Steering	LHD
Terms of Payment	T/T
Truck Class	Heavy Duty
Warranty Period	12 Months
