specification
| Item | Description |
| Hook loader | Designed for 18CBM garbage container |
| (garbage container will be supplied by the client’s site locally) | |
| Overall size | 8,600×2,500×3,300mm(app.) |
| Full pay loading | Full pay loading ≤ 35000 kgs |
| Curb weight | 11,800kg(app.) |
| Capacity | Available in loading 25tons garbage container |
| Max. lifting angle | 49° |
| Lifting time | ≤39s |
| Loading time | ≤35s |
| Unloading time | ≤45s |
| Unloading fast time | ≤19s |
| Chassis Model Number | SX1255MN434 6×4 |
| Chassis Make | Shacman |
| Engine Power | 300HP |
| Engine Type | WP10.300E22 |
| Emission Class Level | Euro 2 |
| Engine displacement | 9.726L |
| Engine Brand | Weichai |
| Wheelbase | 4375+1400mm |
| Front Axle Brand | HANDE |
| Front Axle Rated Loading | 7,500 kg MAN |
| Rear Axle Brand | HANDE |
| Rear Axle Rated Loading | 16000kg MAN double reduction axle, ratio 4.769 |
| Max. Driving Speed | 90km/h |
| Suspension | Multiple leaf spring front & rear/TWO main springs + TWO bolts |
| Clutch | ￠430 diaphragm clutch |
| Frame | 850×300(8+5) |
| Tire Quantities | 10+1spare tire |
| Tire Specification | 12.00R20 |
| Transmission brand | FAST |
| Transmission model | RTD11509C +QH50 PTO |
| Steering | ZF technology |
| Brake | Running brake: Dual circuit compressed air brake |
| Parking brake: Air discharging with spring control | |
| Auxiliary brake: Engine exhaust brake | |
| Without ABS | |
| Cabin | H3000 cab, without top deflector, hydraulic main seat, four-point hydraulic suspension, rod type rearview mirror, electric air conditioner, electric window shaker, manual flip, iron air reservoir, ordinary air filter, square muffler, Gearbox telescopic shaft control, road bumper, fixed boarding pedal, 165Ah maintenance-free battery, 2 hazard warning lights, instrument display in English, SHACMAN logo, full English logo |
| Fuel tank | 400L Aluminum alloy |
