specification
| Vehicle Model | AUMARK-C33 |
| Cabin | Single row/W1995/right rudder |
| Overall dimensions (LxWxH)mm | 5875×2030×2230 |
| Wheelbase(mm) | 3360 |
| Curb weight(kg) | 2600 |
| Gross vehicle weight（kg） | 6495 |
| ENGINE | F3.8s3141/EuroⅢ/3.76L/105kW |
| Gearbox | TS55 |
| Front axle | 2.2T |
| Rear-axle | 5.5T |
| Front suspension/Leaf spring number | 3+1 |
| Rear suspension/Leaf spring number | 6+7 |
| Wheels and tyre size | 6+1(7.00R16) |
| Effective volume of box body (M3) | 4.5 |
| The volume of clean water tank (L) | 170-180 |
| Sewage tank volume (L) | 330-360 |
| High-pressure cleaning water flow (L/min) | 9.83 |
| Operation method | Electronic control + manual control |
| Operating time of turning frame (s) | ≤25 |
| Waste discharge time (s) | ≤30 |
| Hang barrel way | 1120L+240L standard plastic trash can |
| The compartments body | Stainless steel |
